LOGS AND TWIGS. LOGS AND TWIGS.
TOP VIEW OF TOP VIEW OF
Curing Instructions
Note: When lit for the first time the fireplace may emit a slight odor for several hours. This is due to the
curing and "burn in" of external parts and lubricants used in the manufacturing process. This condition
is temporary. Open doors and window to ventilate the room(s) sufficiently.
L
OG
I
NSTALLATION
11
Apply ember material near the grate bars as shown in Figure 9.
Position logs and twigs onto burner as shown in Figure 8.
F
IGURE
8
EMBER MATERIAL
PORTING
3/8"
NOTE: NOTE:
SPECIAL EMBER MATERIAL PROVIDED MAY BE PLACED BETWEEN FRONT SPECIAL EMBER MATERIAL PROVIDED MAY BE PLACED BETWEEN FRONT
PORTING AND GRATE BARS WITH A RECOMMENDED 3/8" SPACING FREE
PORTING AND GRATE BARS WITH A RECOMMENDED 3/8" SPACING FREE
OF EMBER MATERIAL DIRECTLY IN FRONT OF THE FRONT BURNER PORTS
OF EMBER MATERIAL DIRECTLY IN FRONT OF THE FRONT BURNER PORTS
AS SHOWN FOR BEST PERFORMANCE AND EFFECT. BLOCKAGE OF THE
AS SHOWN FOR BEST PERFORMANCE AND EFFECT. BLOCKAGE OF THE
BURNER PORTS MAY CREATE INCREASED SOOT AND CARBON BUILDUP.
BURNER PORTS MAY CREATE INCREASED SOOT AND CARBON BUILDUP.
TO FURTHER ENHANCE THE HEARTH LAVA ROCK MATERIAL MAY BE PLACED TO FURTHER ENHANCE THE HEARTH LAVA ROCK MATERIAL MAY BE PLACED
ON THE HEARTH PAN AREA TO SIMULATE ASHES. LAVA ROCK MUST NOT
ON THE HEARTH PAN AREA TO SIMULATE ASHES. LAVA ROCK MUST NOT
BE PLACED ON TOP OF THE BURNER. ONLY ROCKWOOD IS PERMITTED
BE PLACED ON TOP OF THE BURNER. ONLY ROCKWOOD IS PERMITTED
IN THE BURNER FLAME.
IN THE BURNER FLAME.
FOR PENINSULA AND SEE-THRU CONFIGURATIONS.
TYPICAL BOTH SIDES
TOP VIEW - FRONT LOG AND GRATE BARS TOP VIEW - FRONT LOG AND GRATE BARS
F
IGURE
9
53D9019.
Rev 3 11/07
