FOnboard Serial Port 1
8 Auto BIOS w ill automatically setup the port 1 address.
8 3F8/IRQ4 Enable onboard Serial port 1 and address is 3F8,Using IRQ4. (Default v alue)
8 2F8/IRQ3 Enable onboard Serial port 1 and address is 2F8,Using IRQ3.
8 3E8/IRQ4 Enable onboard Serial port 1 and address is 3E8,Using IRQ4.
8 2E8/IRQ3 Enable onboard Serial port 1 and address is 2E8,Using IRQ3.
8 Disabled Disable onboard Serial port 1.
FOnboard Serial Port 2
8 Auto BIOS w ill automatically setup the port 2 address.
8 3F8/IRQ4 Enable onboard Serial port 2 and address is 3F8,Using IRQ4.
8 2F8/IRQ3 Enable onboard Serial port 2 and address is 2F8,Using IRQ3. (Default Value)
8 3E8/IRQ4 Enable onboard Serial port 2 and address is 3E8,Using IRQ4.
8 2E8/IRQ3 Enable onboard Serial port 2 and address is 2E8,Using IRQ3.
8 Disabled Disable onboard Serial port 2.
FUART Mode S elect
MThis feature allows y ou to determine w hich Infra Red(IR) function of Onboard I/O chip)
8 ASKIR Using as IR and set to ASKIR Mode.
8 IrDA Using as IR and set to IrDA Mode.
8 Normal Using as standard serial port. (Default Value)
8 SCR** Using as smart card Interface.**
F UR2 Duplex Mode(When UART Mode Select isn’t set [Normal])
MThis feature allow s y ou to select the IR modes.
8 Half IR Function Duplex Half. (Default Value)
8 Full IR Function Duplex Full.
FOnBoard Parallel port
MThis feature allows you to select from a given set of parameters if the parallel port uses the
onboard I/O controller.
8 378/IRQ7 Enable onboard LPT port and address is 378, Using IRQ7.(Default Value)
8 278/IRQ5 Enable onboard LPT port and address is 278,Using IRQ5.
8 3BC/IRQ7 Enable onboard LPT port and address is 3BC,Using IRQ7.
8 Disabled Disable onboard parallel port.
**FOR GA-7VAX ONLY
