Technical Data
312145D 11
Technical Data
*Results are maximum readings taken at 6000 psi (41 MPa, 414 bar), with HD519 tip, using
water. Sound power level was tested to ISO 9614-2.
Related Manuals
This manual is available in the following languages. Also see www.graco.com for the latest
translations.
Maximum working pressure:
XTR 5 . . . . . . . . . . . . . . . . . . . . . . . . . . . 5000 psi (35 MPa, 345 bar)
XTR 7 . . . . . . . . . . . . . . . . . . . . . . . . . . . 7250 psi (50 MPa, 500 bar)
Fluid orifice . . . . . . . . . . . . . . . . . . . . . . . 0.090 in. (2.3 mm)
Fluid inlet . . . . . . . . . . . . . . . . . . . . . . . . 1/4 npsm (m)
Max. fluid temperature . . . . . . . . . . . . . . 160°F (71°C)
Sound pressure . . . . . . . . . . . . . . . . . . . 84.3 dB(A)*
Sound power . . . . . . . . . . . . . . . . . . . . . 95.7 dB(A)*
Wetted parts . . . . . . . . . . . . . . . . . . . . . . aluminum, stainless steel, acetal, polyethylene, nylon,
polypropylene, carbide, polyurethane, solvent-resistant
o-rings.
Language Manual
Chinese 312293
Dutch 312138
English 312145
French 312294
German 312295
Italian 312549
Japanese 312296
Korean 312297
Portuguese 312136
Russian 312137
Spanish 312298
Swedish 312139
