Ga-73pvm-s2h motherboard layout, Ga-73pvm-s2h – GIGABYTE LGA775 Socket Motherboard for Intel GA-73PVM-S2H User Manual
Page 7
- 7 -
GA-73PVM-S2H Motherboard Layout
KB_MS
LGA775
ATX
GA-73PVM-S2H
USB
LAN
CD_IN
F_AUDIO
AUDIO
BIOS
PCIE_16
IT8718
IDE
DDRII1
F1_1394
TSB43AB23
PCIE_1
PCI1
BATTERY
CI
CODEC
ATX_12V
ESATA
1394
USB
HDMI
CLR_CMOS
RTL
8211B
CPU_FAN
SATAII0
OPTICAL
PCI2
SYS_FAN
LPT
DVI
VGA
nVIDIA
®
GeForce 7100/
nForce 630i
DDRII2
SATAII2
SATAII1
F_PANEL
COMA
SPDIF_IO
F_USB3 F_USB1 F_USB2
PWR_LED
FDD
