GIGABYTE LGA775 Socket Motherboard for Intel GA-73PVM-S2H - Manual (Page 10)

GA-73PVM-S2H Motherboard - 10 -
1-2 Product Specifications
CPU Š Support for an Intel ® Core TM 2 Extreme processor/
Intel ® Core TM 2 Quad processor/Intel ® Core TM 2 Duo processor/
Intel ® Pentium ® processor Extreme Edition/Intel ® Pentium ® D processor/
Intel ® Pentium ® 4 processor Extreme Edition/Intel ® Pentium ® 4 processor/
Intel ® Celeron ® processor in the LGA 775 package
(Go to GIGABYTE's website for the latest CPU support list.)
Š L2 cache varies with CPU
Front Side Bus Š 1333/1066/800 MHz FSB
Chipset Š nVIDIA ® GeForce 7100/nForce 630i
Memory Š 2 x 1.8V DDR2 DIMM sockets supporting up to 4 GB of system memory
Š Support for DDR2 800/667/533 MHz memory modules
(Go to GIGABYTE's website for the latest memory support list.)
Onboard Graphics Š Integrated in the nVIDIA ® GeForce 7100/nForce 630i chipset
Audio Š Realtek ALC889A codec
Š High Definition Audio
Š 2/4/5.1/7.1-channel
Š Support for S/PDIF In/Out
Š Support for CD In
LAN Š RTL 8211B chip (10/100/1000 Mbit)
Expansion Slots Š 1 x PCI Express x16 slot
Š 1 x PCI Express x1 slot
Š 2 x PCI slots
Storage Interface Š nVIDIA ® GeForce 7100/nForce 630i chipset:
- 3 x SATA 3Gb/s connectors (SATAII0, SATAII1, SATAII2) supporting up
to 3 SATA 3Gb/s devices
- 1 x eSATA 3Gb/s port on the back panel supporting up to 1 SATA
3Gb/s device
- Support for SATA RAID 0, RAID 1, RAID 5, and RAID 0+1
- 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
Š iTE IT8718 chip:
-
1 x floppy disk drive connector supporting up to 1 floppy disk drive
IEEE 1394a Š T.I. TSB43AB23 chip
Š Up to 2 IEEE 1394a ports (1 on the back panel, 1 via the IEEE 1394a bracket
connected to the internal IEEE 1394a header)
USB Š Integrated in the nVIDIA ® GeForce 7100/nForce 630i chipset
Š Up to 10 USB 2.0/1.1 ports (4 on the back panel, 6 via the USB brackets
connected to the internal USB headers)
