Installation Preparation
Micr owav e Oven
Tools and materials required:
• 3-prong grounded electrical receptacle.
• Electrical cable, 2-wire with ground, No. 14 minimum,
as required.
Monogram microwave ovens require a 120 volt, 60 Hz
power supply, protected by a time delay fuse or circuit
breaker.
ZEM200WV oven is supplied with a power cord 57"
long for which a properly grounded 3-prong electrical
receptacle is required.
• 800 watt* oven ZEM200WV draws 1360 watts,
with a 13 amp load.
*IEC-705 test procedure
Note: Do not use an extension
cord with these appliances.
• Install a 3-prong grounded receptacle.
• Receptacle may be within opening (shaded area in
diagram):
– If using this installation, be sure opening is
sufficiently deep to accommodate power cord and
plug (18" min.).
• Receptacle may also be placed outside shaded area,
within reach of oven’s 57" power cord. In this case,
opening need only be 16" deep.
ZEM200WV
In-wall
installation
Electrical
supply
6
