Design Information
Mic r owa v e Oven
Wall Cutout ZEM200WN
3
Designed for versatility, this Monogram microwave
oven adapts to virtually any installation. Accessory kit
JX827WN is required for custom in-wall installation.
ZEM200WV
White electronic
microwave oven
ZEM200WV
A - 12 -5/16" (284 mm)
B - 23-13/16" (605 mm)
C - 11-3/16" (284 mm)
(includes feet)
Note: When installed, trim kit
will require wall space 26-1/8"
W x 16-1/4" H for clearance.
This microwave oven can be used on the countertop,
built into a wall or suspended beneath a cabinet.
Accessory kit JX827WN is necessar y for custom in-wall
installation.
• Do not install this microwave oven above a cooktop,
range or other heating surface.
• Using the accessory kit, this microwave oven can be
installed alone or over any Monogram single electric
wall oven.
All necessary hardware for under cabinet installation
comes packed with the product.
Refer to “Cabinetry” for complete details on prepara-
tion for in-wall installation.
If you wish to mount the ZEM200WV beneath a
cabinet:
• Cabinet must be wood or metal, in good condition.
• Cabinet bottom must be capable of supporting an
additional 90 pounds.
• Wood cabinet bottom must be at least 3/16" thick
masonite or plywood.
• Underside of cabinet must be at least 24" wide.
• 12" deep cabinet is preferred, though oven may be
mounted on shallower cabinetry.
• A 3-prong grounding wall receptacle must be within
reach of the 57" power cord:
– Receptacle should not be directly behind oven, but
should be out of view when oven is installed.
• Check that cabinet is securely installed, using more
than two screws at top:
– If not, add two screws at cabinet bottom, making
sure they enter wall studs at least 1/2".
• Refer to “Installation” for further details.
Model
available
Dimensions
and clearances
Installation
options
Advance
planning
