The connection procedure is straightforward. Simply insert the DC leads to the
S14H’s power terminals, positive (+) and negative (-) screws. The use of Ground (GND) is
optional; it connects to the S14H chassis. Ensure that each lead is securely tightened from
the top, as shown here.
NOTE: Always use a voltmeter to measure the voltage of the incoming power supply
and figure out the +ve potential lead or -ve potential lead. The more +ve potential lead
will connect to the post labeled “+ve” and the rest to the “-ve”.
The GND can be hooked up last.
When power is applied, the green PWR LED will illuminate.
