GarrettCom PS14P User Manual
Page 57
S14 & PS14P (PoE) Convenient Switches Installation and User Guide (01/06)
50
www GarrettCom com
.
.
3.6 Powering the S14H & S14P (DC
internal) with 12V, 24V or –48VDC power
input
Each Magnum S14H/S14P is
reliably equipped with a Direct DC power
supply, and have built-in screw terminals for
secure attachment of the power leads. Three
models support a range of power input types.
The three model choices are for use with
12VDC, 24VDC or -48VDC power. DC power input may be chosen for high-availability.
The extended temperature capability of the Direct DC-powered S14P’s can go
into temperature uncontrolled environments, rated at –40`C to +75`C. The DC jack is also
