S14 & PS14P (PoE) Convenient Switches Installation and User Guide (01/06)
42
www GarrettCom com
.
.
Secure attachment of mounting
clips for Panel-
3.0 INSTALLATION
This section describes the installation of the Magnum S14-Series & PS14P(PoE)
Convenient Switches, including location,
mountings, power supply and media
connection.
3.1 Locating the Convenient Switch Unit
All the S14-Series & PS14P(PoE) Switches
operate in transparent half-and full-duplex
mode. The store and forward switch easily
take care of the network traffic and can be
used as a useful economical tool to expand the
existing network. The compact and
lightweight design of the Magnum S-Series allows it to be easily installed in almost any
location. Metal mounting clips and screws are included for a rugged and secure mounting
in any orientation. An option DIN-Rail bracket is available.
Installation of the Magnum S14-Series & PS14P(PoE) Switches is a simple procedure.
The installation location is dependent upon the physical layout of the Ethernet network and
