S14 & PS14P (PoE) Convenient Switches Installation and User Guide (01/06)
v
www GarrettCom com
.
.
3.7
S14H & S14P, DC-powered, Installation ......................................... 52
3.7.1
Power Requirement for PS14P(PoE) Power Source Switch.......... 54
3.8
Connecting Twisted Pair (RJ-45 ports).............................................. 55
3.8.1
Connecting Twisted Pair ( Unshielded or Shielded)................. 56
3.8.2
Connections to NICs which support Auto-Neg RJ-45 ports...... 57
4.0
OPERATION ....................................................................................... 58
4.1
Dual-Speed Functionality, and Switching ......................................... 58
4.2
Auto-cross (MDIX), Auto-negotiation and Speed-sensing................ 60
4.3:
Dual LEDs, Front-panel and side-panel (S14-Series & PS14P(PoE))62
5.1
Before Calling for Assistance ............................................................ 64
5.2
When Calling for Assistance ............................................................. 65
5.3
Return Material Authorization (RMA) ProcedureError! Bookmark not defined
5.4
Shipping and Packaging Information................................................. 67
APPENDIX A: WARRANTY INFORMATION......................................... 69
Revisions
01/06: Updated the PS14P(POE) Power Source Switch
Rev B 05/05: Added
Magnum
PS14P(POE) Power Source Switch
