GarrettCom PS14P User Manual

Page 18

Text mode
Original mode

S14 & PS14P (PoE) Convenient Switches Installation and User Guide (01/06)

www GarrettCom com

Magnum PS14P (PoE) Power Source Switch (model and descriptions)

PS14P = ,Premium rated, four 10/100 RJ-45 ports Switch in a compact package, rated for un-
controlled(outdoor) env. All four RJ-45 Ethernet ports support Power Source PoE as per the IEEE
802.3ad standard. Includes integral -48V DC terminal block for power unit.

NOTE: If you want a heavy-duty Industrial power supply that plugs into AC and delivers -48BDC at
50 watts to support one PS14P-48VDC Switch and up to 4 attached PoE devices, Try this URL –

http://www.lanstore.com/ps.htm

MC14-TRAY = 19” Rack-mount tray for 14-series Switch models

DIN-RAIL-MC2 = Metal DIN-Rail mounting bracket for one PS14P Switch

2.0 INTRODUCTION

This section describes S14-Series models, including appearance, features and

typical applications.
