Grizzly G9983 User Manual
Page 51
G9983 15" Open-End Wide-Belt Sander
-49-
REF
PART #
DESCRIPTION
REF
PART #
DESCRIPTION
401 P9983401 MACHINE FRAME
402 P9983402 ACCESS DOOR RH
403 P9983403 ACCESS DOOR LH
404 P9983404 LOCK
405 P9983405 OPERATING PANEL
406 P9983406 LOAD METER
407 P9983407 POWER INDICATOR
408 P9983408 START BUTTON
409 P9983409 STOP BUTTON
410 P9983410 EMERGENCY STOP BUTTON
411 PS47M
PHLP HD SCR M6-1.0 X 25
412 P9983412 PRESSURE ROLLER FRAME
413 PLW03M
LOCK WASHER 6MM
414 PSB06M
CAP SCREW M6-1.0 X 25
415 P9983415 TILTING ARM
416 PSS26M
SETSCREW M5-08 X 6
417 P9983417 SPRING
418 P9983418 SPRING HOOK
419 PW01M
FLAT WASHER 8MM
420 PN03M
HEX NUT M8
421 P9983421 SET PIN
422 PR01M
EXT RETAINING RING 10MM
423 P9983423 BEARING COVER
424 P6001
BEARING 6001ZZ
425 P9983425 PRESSURE ROLLER
426 P9983426 PRESSURE SHAFT
427 P9983427 SPECIAL NUT M8-1.25
428 PSS42M
SETSCREW M8-1.25 X 50
429 P9983429 PLASTIC CONNECTOR L6-
1
⁄
8
"
430 P9983430 SWITCHING VALVE
1
⁄
8
"
431 P9983431 SILENCER
1
⁄
8
"
432 P9983432 PLASTIC CONNECTOR C6-
1
⁄
8
"
433 P9983433 LINING
434 PS49M
PHLP HD SCR M3-.5 X 5
436 PS02M
PHLP HD SCR M4-.7 X 12
437 P9983437 TOP ALUMINUM COVER
438 PS06M
PHLP HD SCR M5-.8 X 20
439 P9983439 PLASTIC CONNECT M6 X
1
⁄
4
"
440 P9983440 PLATE
441 P9983441 DIAPHRAGM
442 P9983442 BOTTOM ALUMINUM COVER
443 P9983443 PLASTIC CONNECT
1
⁄
8
" X
1
⁄
8
"
444 P9983444 CUP
1
⁄
4
"
445 P9983445 CONNECTOR
1
⁄
4
"
446 P9983446 PLASTIC CONNECT C6-
1
⁄
4
"
501 P9983501 SWITCHING VALVE
502 PS12M
PHLP HD SCR M3-.5 X 6
503 PS12M
PHLP HD SCR M3-.5 X 6
504 P9983504 LIMIT SWITCH PANEL
505 P9983505 SILENCER
1
⁄
8
"
506 P9983506 PLASTIC CONNECT L6-
1
⁄
8
"
507 P9983507 PLASTIC CONNECT C6-
1
⁄
8
"
508 P9983508 SENSOR PIN
509 P9983509 LIMIT SWITCH 8166
510 PS50M
PHLP HD SCR M3-.5 X 12
511 PS50M
PHLP HD SCR M3-.5 X 12
512 P9983512 AIR VALVE
1
⁄
8
"
513 P9983513 PLASTIC CONNECT C6-
1
⁄
8
"
514 P9983514 PLASTIC CONNECT L6-
1
⁄
8
"
515 PS52M
PHLP HD SCR M4-.7 X 20
516 P9983516 PLASTIC CONNECT 6Y
517 P9983517 PLASTIC CONNECT 6T
518 P9983518 PLASTIC CONNECT C6-
1
⁄
8
"
519 PN11
HEX NUT
3
⁄
8
"-24
520 P9983520 AIR EYELET (OUT)
3
⁄
8
"
521 P9983521 BRASS NUT
3
⁄
8
"-UNF
522 P9983522 BUSHING 10MM
523 P9983523 PLASTIC CONNECT
1
⁄
8
" X
3
⁄
8
"
524 P9983524 AIR VALVE
1
⁄
8
"
525 P9983525 PLASTIC CONNECT L6-
1
⁄
8
"
526 P9983526 SOLENOID VALVE
1
⁄
8
" X 220V
527 P9983527 PLASTIC CONNECT B6-
1
⁄
8
"
528 P9983528 PLASTIC CONNECT L6-
1
⁄
8
"
529 P9983529 SILENCER
1
⁄
8
"
530 P9983530 CONNECTOR
531 PS25M
PHLP HD SCR M4-.7 X 35
532 PN04M
HEX NUT M4-.7
533 P9983533 PRESSURE GAUGE
K-1000FR2
534 P9983534 PLASTIC CONNECT L6-
1
⁄
4
"
535 P9983535 AIR COCK
1
⁄
4
" X
5
⁄
16
"
536 PW03M
FLAT WASHER 6MM
537 PS14M
PHLP HD SCR M6-1.0 X 12
538 P9983538 TENSION CYLINDER
63 X 40ST
539 P9983539 PLASTIC CONNECT C6-
1
⁄
8
"
540 P9983540 SILENCER
1
⁄
4
"
