Unpacking
The Model G9983 Wide-belt Sander is shipped
from the manufacturer in a carefully packed car-
ton. If you discover your machine is damaged
after you have signed for delivery, and the truck
and driver are gone, you will need to file a freight
claim with the carrier. Save the containers and all
packing materials for possible inspection by the
carrier or its agent. Without the packing materials,
filing a freight claim can be difficult.
If you need
assistance determining whether you need to file a
freight claim, or with the procedure to file one,
please contact our Customer Service.
Piece Inventory
After all the parts have been removed from the
carton, you should have:
• Sanding Unit
• Tool Box
• Combo Wrench 8/10MM
• Combo Wrench 11/13MM
• Combo Wrench 12/14MM
• Combo Wrench 17/19MM
• Combo Box-Wrench 30/37MM
• Phillips Screwdriver
• Hex Wrench Set
• Platen Puller
• Platen
• Door Handle (2)
• Handwheel Handle
• Sanding Belt #180
• Sanding Belt #240
In the event that any non-proprietary parts are
missing (e.g. a nut or a washer), we would be
glad to replace them, or for the sake of expedien-
cy, replacements can be obtained at your local
hardware store. Loose parts in the sander crate
(not including hardware) are shown in
Figure 6 .
When you are completely satisfied with the con-
dition of your shipment, you should inventory its
parts.
NOTICE
A full parts list and breakdown can be found
toward the end of this manual. For easier
assembly, or to identify missing parts,
please refer to the detailed illustrations at
the end of the manual.
The Model G9983 is a
heavy machine—
approx. 1000 lb. DO
NOT over-exert yourself
while unpacking or
moving your machine.
You will need assis-
tance and power equip-
ment. Serious personal
injury may occur if safe
moving methods are not
followed.
Figure 6. Loose parts (not including hardware)
for the Model G9983.
