Crathco ® Remote Beverage Freezers Page 29
Exploded View Models 3342/3352 Motor Assembly
Base Assembly Refrigeration Models 3342/3352
Item Part Number Description
1 W0170014 Consistency Cntrl.
2 W0210169 Motor Cradle
3 W0210200 Frame Bottom Plate
4 W0321013 Motor Adj. Nut
5 W0321020 Motor Assembly
6 W0380009 Flange Bearing
7 W0451000 Pulley
Item Part Number Description
2 W0650501 Access Valve
4 W0650104 Automatic Exp. Valve
6 W1650005 Solenoid Valve
7 W0200312 Filter Drier
8 W0620117 3/8" Quick Disconnect
9 W0620118 5/8" Quick Disconnect
21 W0650416 Needle Valve
22 W0650116 Capillary Tube
