5
M8 Split
Washer (97)–10
Wave Washer
(80)–2
M10 x 80mm Patch Screw (93)–4
Large Wave
Washer (89)–2
M8 x 22mm
Washer (31)–2
M8 Locknut
(94)–2
M8 x 58mm Shoulder
Bolt (104)–2
M8 x 19mm Patch
Screw (86)–6
M4 x 16mm
Screw (78)–4
M10 Washer
(95)–4
M10 x 20mm Patch
Screw (68)–4
M8 x 40mm Patch
Screw (90)–6
M8 x 12mm Patch
Screw (84)–6
M10 Spring
Washer (99)–4
M4 x 25mm Screw
(114)–2
ASSEMBLY
To hire an authorized service technician to assemble the elliptical exerciser, call 1-800-445-2480.
Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the
packing materials. Do not dispose of the packing materials until assembly is completed.
In addition to the included tool(s), assembly requires a Phillips screwdriver , an adjustable
wrench , and a rubber mallet .
As you assemble the elliptical exerciser, use the drawings below to identify small parts. The number in parenthe-
ses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The
number following the parentheses is the quantity needed for assembly. Note: Some small parts may have
been preassembled. If a part is not in the hardware kit, check to see if it has been preassembled.
