Graco Inc. Ultra Max II 795 - Manual (Page 13)

12
Ultimate MX II
695
/
795
/
1095
/
1595 Standard
Ultimate MX II 1095
Standard
DESCRIPTION PART #:
Ultimate MX II 1095 Hi-Boy 826131
SpecificationS :
MAX TIP SIZE: 0.035-1 Gun
0.027-2 Guns
0.021-3 Guns
MAX GPM [LPM]: 1.20 [4.5]
MAX PSI [BAR]: 3300 [227]
MOTOR: 2.4 hp Brushless DC
includeS:
• Contractor Gun
• RAC 5 517 SwitchTip and Guard
• 1/4 in x 50 ft [6.4 mm x 15 m]
FlexPro Airless Hose
• • • • • •
Ultimate MX II 1595
Standard
DESCRIPTION PART #:
Ultimate MX II 1595 Hi-Boy 826133
Ultimate MX II 1595
Hi-Boy [Canada] 826135
SpecificationS :
MAX TIP SIZE: 0.039–1 Gun
0.029–2 Guns
0.023–3 Guns
MAX GPM [LPM]: 1.35 [5.1]
MAX PSI [BAR]: 3300 [227]
MOTOR: 2.8 hp Brushless DC
includeS :
• Contractor Gun
• RAC 5 517 SwitchTip and Guard
• 1/4 in x 50 ft [6.4 mm x 15 m]
FlexPro Airless Hose
ELECTRICS • LARGE ELECTRICS • LARGE ELECTRICS • LARGE ELECTRICS • LARGE ELECTRICS • LARGE ELECTRICS ELECTRICS
LARGE ELECTRICS • LARGE ELECTRICS • LARGE ELECTRICS • LARGE ELECTRICS • LARGE ELECTRICS • LARGE LARGE
ELECTRICS ELECTRICS • • LARGE LARGE ELECTRICS ELECTRICS • • LARGE LARGE ELECTRICS ELECTRICS • • LARGE LARGE ELECTRICS ELECTRICS • • LARGE LARGE ELECTRICS ELECTRICS • • LARGE LARGE ELECTRICS ELECTRICS
Endurance Pump
 Proven design and rugged
construction
 Long-life V-Max Blue packings,
Chromex rod and hardened
Stainless Steel cylinder
 QuikAccess intake valve
requires only a hammer to
access the intake ball to
easily clean or clear debris
Exclusive ProConnect Pump Removal and
Installation System
[Ultimate MX II 1095/1595 sprayers only]
 Proven, reliable design for ease of pump replacement
 ProConnect allows you to remove and replace your pump in
seconds
without any without without tools any any
 Makes your work easier work work – saving you time and money on the job
Chrome Plated, Welded Steel Carts
 Thick chrome Thick Thick over steel to withstand rugged environments
 Retractable handle doubles as a hose wrap for simple removal of coiled hose
 Pneumatic wheels roll easily over rough terrain
 Hi-Boy TiltBack cart TiltBack TiltBack design makes bucket changes fast and easy
Lo-Boy model shown
