The Ultimate MX II 490/495/595 brings the leading technology and performance of Graco’s of of
larger Ultra Max II models into these compact and lightweight sprayers. The Ultimate MX II
490/495/595 sprayers are the best choice for professionals looking for superior
performance and control for daily use on residential jobs.
Ultimate MX II 490
/
495
/
595
Ultimate MX II 490
DESCRIPTION PART #:
Ultimate MX II 490 Stand 825028
Ultimate MX II 490 Hi-Boy 825036
Ultimate MX II 490 Lo-Boy 825029
SpecificationS:
MAX TIP SIZE: 0.023
MAX GPM [LPM]: 0.54 [2.0]
MAX PSI [BAR]: 3300 [227]
MOTOR: 1.0 hp Brushless DC
includeS:
• Contractor Gun
• RAC 5 517 SwitchTip and Guard
• 1/4 in x 50 ft [6.4 mm x 15 m]
FlexPro Airless Hose
• • • • • •
Ultimate MX II 495
DESCRIPTION PART #:
Ultimate MX II 495 Stand 825037
Ultimate MX II 495 Hi-Boy 825039
Ultimate MX II 495 Lo-Boy 825038
SpecificationS:
MAX TIP SIZE: 0.025
MAX GPM [LPM]: 0.60 [2.3]
MAX PSI [BAR]: 3300 [227]
MOTOR: 1.2 hp Brushless DC
includeS:
• Contractor Gun
• RAC 5 517 SwitchTip and Guard
• 1/4 in x 50 ft [6.4 mm x 15 m]
FlexPro Airless Hose
• • • • • •
Ultimate MX II 595
DESCRIPTION PART #:
Ultimate MX II 595 Hi-Boy 825045
Ultimate MX II 595 Lo-Boy 825046
SpecificationS:
TIP SIZE: 0.027
MAX GPM [LPM]: 0.70 [2.6]
MAX PSI [BAR]: 3300 [227]
MOTOR: 1.4 hp Brushless DC
includeS:
• Contractor Gun
• RAC 5 517 SwitchTip and Guard
• 1/4 in x 50 ft [6.4 mm x 15 m]
FlexPro Airless Hose
FT 500
Stand model shown
Endurance Pump
 Long-life V-Max Blue packings,
Chromex rod and hardened
Stainless Steel cylinder
 design and
construction
 QuikAccess intake valve requires
hammer to access the
ball to easily clean
debris
ELECTRICS • SMALL ELECTRICS • SMALL ELECTRICS • SMALL ELECTRICS • SMALL ELECTRICS • SMALL ELECTRICS
• SMALL ELECTRICS • SMALL ELECTRICS • SMALL ELECTRICS • SMALL ELECTRICS • SMALL ELECTRICS • SMALL
ELECTRICS ELECTRICS • • SMALL SMALL ELECTRICS ELECTRICS • • SMALL SMALL ELECTRICS ELECTRICS • • SMALL SMALL ELECTRICS ELECTRICS • • SMALL SMALL ELECTRICS ELECTRICS • • SMALL SMALL ELECTRICS ELECTRICS
MaxPower Brushless
DC Motor
 No brushes to replace
 Compact, lightweight motor lightweight lightweight delivers motor motor
higher horsepower higher higher per horsepower horsepower wall per per amp
 Enclosed design protects internal motor
components from dirt, dust and
dust dust
overspray to overspray overspray extend motor life motor motor
Chrome Plated, Welded Steel Carts
 Thick chrome Thick Thick over steel to withstand rugged environments
 Retractable handle doubles as a hose wrap for simple removal of coiled hose
 Semi-pneumatic wheels roll easily over rough terrain
Easy Out Pump Filter
 filtering area
tip clogs and
a quality finish
 Easy Out design filters from
inside out – filters won’t
stuck or
stuck stuck collapse
when dirty
 Filter removes simply with
cap for less mess
SmartControl 2.0
Pressure Control
 Advanced microprocessor
control delivers
consistent spray
without pressure
fluctuation at
spraying pressures
 Zero deadband
spraying pressures
makes this line
sprayers ideal
finish spraying
