Grizzly 12" Jointer w/spiral cutterhead manual insert g0609X - Manual (Page 6)

Model g0609X -5-
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0609001 CUTTERHEAD GUARD 45 P0609045 SHAFT
4 PFH23M FLAT HD SCR M8-1.25 X 16 46 PLW06M LOCK WASHER 10MM
5 P0609005 SPECIAL FLAT WASHER 47 PB32M HEX BOLT M10-1.5 X 25
6 PSS04M SET SCREW M6-1 X 12 48 P0609048 BUSHING
7 P0609007 ADAPTER 49 P0609049 WORM GEAR
8 P0609008 TORSION SPRING 50 PK12M KEY 5 X 5 X 30
9 P0609009 SHAFT COLLAR 51 P0609051 GEAR
10 PSS04M SET SCREW M6-1 X 12 52 P0609052 WORM
11 P0609011 SHAFT 53 PK37M KEY 4 X 4 X 16
12 P0609012 CUTTERHEAD SCREW 54 P0609054 SLIDE STOP BLOCK
13 PLW06M LOCK WASHER 10MM 55 P0609055 SLIDE STOP BLOCK
14 PW04M FLAT WASHER 10MM 55-1 PSS16M SET SCREW M8-1.25 X 10
15 PK111 KEY 8 X 8 X 60 56 P0609056 SPECIAL FLAT SCREW
16 P0609016 CUTTERHEAD PULLEY 57 P0609057 POINTER
17 PVA53 V-BELT A-53 4L530 58 PW02M FLAT WASHER 5MM
18 PSB02M CAP SCREW M6-1 X 20 59 PS09M PHLP HD SCR M5-.8 X 10
19 P0609019 BEARING COVER 60 PB73M HEX BOLT M10-1.5 X 50
20 P6206 BALL BEARING 6206ZZ 61 P0609061 CLAMP BLOCK
21 P0609021 BEARING SUPPORT 62 PLW06M LOCK WASHER 10MM
22 P0452Z001 DRIVER BIT TORX T20 63 PW04M FLAT WASHER 10MM
23 P0609X023 SPIRAL CUTTERHEAD 12" 64 P0609064 CLAMPING BLOCK
24 P0452Z002 INDEXABLE INSERT 14 x 14 x 2 65 P0609065 CLAMP PLATE
25 P0452Z009 L-WRENCH TORX T20 66 PHTEK4M TAP SCREW M4 X 8
26 PFH35M FLAT HD TORX SCR T20 M6-1 X 15 67 P0609067 STOP BUTTON
27 P0609027 BEARING SUPPORT 68 P0609068 START BUTTON
28 P62042RZ BALL BEARING 62042RZ 69 P0609069 SWITCH BOX
29 PW01M FLAT WASHER 8MM 70 PFS14M FLANGE SCREW M8-1.25 X 16
30 P0609030 CUTTERHEAD SCREW 71 P0609071 SWITCH BOX BRACKET
31 PN02M HEX NUT M10-1.5 72 PB32M HEX BOLT M10-1.5 X 25
32 P0609032 BEARING COVER 73 PLW06M LOCK WASHER 10MM
33 PSB02M CAP SCREW M6-1 X 20 74 PW04M FLAT WASHER 10MM
34 PB156 HEX BOLT M10-1.5 X 150 75 P0609075 BUTTON PLATE
35 PSS71M SET SCREW M10-1.5 X 60 76 P0609076 BALL STRAIN RELIEF
36 P0609036 BASE 77 PAW10M HEX WRENCH 10MM
37 PSS04M SET SCREW M6-1 X 12 78 PAW08M HEX WRENCH 8MM
38 PW04M FLAT WASHER 10MM 79 PAW03M HEX WRENCH 3MM
39 P0609039 LOCK HANDLE 80 PWR1719 WRENCH 17 X 19
40 PSS03M SET SCREW M6-1 X 8 81 PWR1214 COMBO WRENCH 12/14MM
41 P0609041 ECCENTRIC BUSHING 82 PWR1012 COMBO WRENCH 10/12MM
42 P0609042 SHAFT 84 P0609084 BUSHING
42-1 P0609042-1 LEFT TORSION SPRING 85 P6202 BALL BEARING 6202ZZ
42-2 P0609042-2 RIGHT TORSION SPRING 86 PB06M HEX BOLT M8-1.25 X 12
43 P0609043 STOP BLOCK 87 PW03M FLAT WASHER 6MM
44 PR21M INT RETAINING RING 35MM 88 PB02M HEX BOLT M6-1 X 12
Jointer breakdown parts list
