-60-
G0613/14 Swivel Mast Metal Cutting Bandsaw
Parts List (G0613)
REF PART # DESCRIPTION REF PART # DESCRIPTION
300 P0613300 FRONT PANEL 311 P0613311 WORM SHAFT
301 P0613301 REAR PANEL 312 P0613312 O-RING
302 P0613302 SIDE PANEL 313 P0613313 OUTPUT SHAFT COVER
303 PN03M HEX NUT M8-1.25 314 P0613314 OIL SEAL
304 PW01M FLAT WASHER 8MM 315 PSB02M CAP SCREW M6-1 X 20
305 PB03M HEX BOLT M8-1.25 X 16 316 P6008 BALL BEARING 6008
306 PW04M FLAT WASHER 10MM 317 P0613317 WORM WHEEL
307 PB14M HEX BOLT M10-1.5 X 35 318 P0613318 OUTPUT SHAFT
308 P0613308 MOTOR FLANGE 319 P6008 BALL BEARING 6008
309 P0613309 O-RING 320 P0613320 OIL SEAL
310 P6006 BALL BEARING 6006ZZ 321 PB10M HEX BOLT M6-1 X 25
311 P0613311 WORM SHAFT 322 P0613322 HOUSING
312 P0613312 O-RING 323 P0613323 OIL SEAL
308 P0613308 MOTOR FLANGE 324 P6204 BALL BEARING 6204ZZ
309 P0613309 O-RING 325 PR79M EXT RETAINING RING 47MM
310 P6006 BALL BEARING 6006ZZ 326 P0613326 OIL SEAL
REF PART # DESCRIPTION REF PART # DESCRIPTION
300 P0614300 FRONT PANEL 311 P0614311 WORM SHAFT
301 P0614301 REAR PANEL 312 P0614312 O-RING
302 P0614302 SIDE PANEL 313 P0614313 OUTPUT SHAFT COVER
303 PN03M HEX NUT M8-1.25 314 P0614314 OIL SEAL
304 PW01M FLAT WASHER 8MM 315 PSB02M CAP SCREW M6-1 X 20
305 PB03M HEX BOLT M8-1.25 X 16 316 P6008 BALL BEARING 6008
306 PW04M FLAT WASHER 10MM 317 P0614317 WORM WHEEL
307 PB14M HEX BOLT M10-1.5 X 35 318 P0614318 OUTPUT SHAFT
308 P0614308 MOTOR FLANGE 319 P6008 BALL BEARING 6008
309 P0614309 O-RING 320 P0614320 OIL SEAL
310 P6006 BALL BEARING 6006ZZ 321 PB10M HEX BOLT M6-1 X 25
311 P0614311 WORM SHAFT 322 P0614322 HOUSING
312 P0614312 O-RING 323 P0614323 OIL SEAL
308 P0614308 MOTOR FLANGE 324 P6204 BALL BEARING 6204ZZ
309 P0614309 O-RING 325 PR79M EXT RETAINING RING 47MM
310 P6006 BALL BEARING 6006ZZ 326 P0614326 OIL SEAL
Parts List (G0614)
