Grizzly G0614 - Manual (Page 53)

G0613/14 Swivel Mast Metal Cutting Bandsaw
-51-
Parts List (G0614)
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PSB64M CAP SCREW M10-1.5 X 25 43 P0614043 HANDLE
2 PW04M FLAT WASHER 10MM 44 P0614044 HANDLE PIPE
3 P0614003 SHAFT 45 PSBS05M BUTTON HD CAP SCR M6-1 X 20
4 P0614004 ANCHOR BLOCK 46 PSS20M SET SCREW M8-1.25 X 8
5 P0614005 HEX NUT M16-2 47 PSB40M CAP SCREW M8-1.25 X 35
6 P6205 BALL BEARING 6205 48 P0614048 BLADE ADJUSTMENT BAR
7 P0614007 BODY FRAME 49 PSB58M CAP SCREW M8-1.25 X 12
8 PN01M HEX NUT M6-1 50 PS09M PHLP HD SCR M5-.8 X 10
9 PB29M HEX BOLT M6-1 X 30 51 PW02M FLAT WASHER 5MM
10 P0614010 KNOB 52 P0614052 BLADE COVER (FRONT)
11 P0614011 BLADE TENSION HANDLE 53 P0614053 ADJUSTMENT BLOCK (FRONT)
12 P0614012 CONCAVE WASHER 53-1 P0614053-1 FLOW VALVE
13 P0614013 LEADSCREW 53-2 P0613053-2 COOLANT HOSE
14 P0614014 CAP SCREW M8-1.25 X 25L 53-3 P0613053-2 STEEL "T"
15 P0614015 FIXED BLOCK 54 P0614054 GUIDE
16 PSB13M CAP SCREW M8-1.25 X 30 55 P0614055 GUIDE
17 PLW04M LOCK WASHER 8MM 56 PSBS05M BUTTON HD CAP SCR M6-1 X 20
18 P0614018 REDUCER BLOCK 57 P0614057 ECCENTRIC GUIDE
19 PW01M FLAT WASHER 8MM 58 P608A BALL BEARING 608
20 PSB31M CAP SCREW M8-1.25 X 25 59 PS22M PHLP HD SCR M5-.8 X 25
21 P0614021 GEARBOX 60 P0614060 ECCENTRIC GUIDE
22 P0614022 MOTOR 220V 3-PHASE 62 PSB10M CAP SCR M5-.8 X 15
22-1 P0614022-1 FAN 63 PSB40M CAP SCREW M8-1.25 X 35
22-2 P0614022-2 COVER 64 PLW04M LOCK WASHER 8MM
25 PB32M HEX BOLT M10-1.5 X 25 65 P0614065 ADJUSTMENT BLOCK (REAR)
26 PW04M FLAT WASHER 10MM 66 PSB58M CAP SCREW M8-1.25 X 12
27 P0614027 KEY 8 X 7 X 35 67 P0614067 CHIP PLATE
28 P0614028 OUTPUT SHAFT 68 P0614068 BLADE COVER (REAR)
29 PK109M KEY 7 X 7 X 35 69 PW02M FLAT WASHER 5MM
30 P6206 BALL BEARING 6206 70 PS09M PHLP HD SCR M5-.8 X 10
31 P0614031 SPRING SUPPORT 71 P0614071 DRIVE WHEEL
32 P0614032 TENSION SPRING 72 PW04M FLAT WASHER 10MM
34 PSB06M CAP SCREW M6-1 X 25 73 PB32M HEX BOLT M10-1.5 X 25
35 PLW03M LOCK WASHER 6MM 75 P0614075 MAIN BLADE COVER
36 P0614036 FRAME PIVOT SHAFT 76 PW03M FLAT WASHER 6MM
37 P0614037 CHIP COVER 77 P0614077 KNOB SCREW M6-1 X 10
38 P0614038 TAPERED BEARING 32006 78 P0614078 SAW BLADE
39 P0614039 LEVER BOLT 3/8-24 X 1 79 P0614079 IDLER WHEEL
40 P0614040 FIXED BLOCK 80 PR11M EXT RETAINING RING 25MM
41 PSS06M SET SCREW M8-1.25 X 16
