G0613/14 Swivel Mast Metal Cutting Bandsaw
-55-
Parts List (G0614)
REF PART # DESCRIPTION REF PART # DESCRIPTION
100 P0614100 VISE JAW BRACKET(REAR) 131 P0614131 NUT
101 P0614101 VISE JAW ADJUSTABLE ROD 132 P0614132 ADJUSTABLE HANDLE
102 P0614102 RETAINER 133 P0614133 HEX PLUG 3/8PT
103 P0614103 SWIVEL ARM 134 PSB01M CAP SCR M6-1 X 16
103-1 PB14M HEX BOLT M10-1.5 X 35 135 PW03M FLAT WASHER 6MM
104 PN02M HEX NUT M10-1.5 136 P0614136 PUMP 220V, 3-PHASE
105 PB01M HEX BOLT M10-1.5 X 30 136-1 P0614136-1 PLASTIC TUBING
106 P0614106 DISTANCE SET ROD 140 P0614140 CYLINDER
107 P0614107 BRACKET 141 P0614141 WATERPROOF LIMIT SWITCH
108 P0614108 LEVER 141-1 P0614141-1 WATERPROOF POWER CORD
109 PS26M PHLP HD SCR M6-1 X 20 142 P0614142 SWITCH PLADE
110 P0614110 BALL BEARING 32006 143 PS75M PHLP HD SCR M5-.8 X 35
111 P0614111 BUSHING 144 PSB124M CAP SCREW M12-1.75 X 80
112 P0614112 BEARING COVER 145 PSB90M CAP SCREW M10-1.5 X 55
113 P0614113 SPANNER NUT M30 X 1.5 181 PSBS01M BUTTON HD CAP SCR M8-1.25 X 20
114 PSB01M CAP SCREW M6-1 X 16 182 PW01M FLAT WASHER 8MM
115 PLW03M LOCK WASHER 6MM 183 P0614083 WHEEL
116 P0614116 SPRING ANCHOR 184 PSS20M ROLL PIN
117 P0614117 L-BRACKET 185 P0614085 BEARING COVER
118 PLW04M LOCK WASHER 8MM 186 P0614086 BALL BEARING 51106
119 PSB31M CAP SCREW M8-1.25 X 25 187 P0614087 VISE HANDLE
120 PS05M PHLP HD SCR M5-.8 X 8 188 P0614088 TENSION SPRING
121 P0614121 SCREEN 189 P0614089 BUSHING
122 P0614122 BASE 190 PSB06M CAP SCREW M6-1 X 25
122-1 P0614122-1 BASE CABINET 191 P0614091 VISE JAW BRACKET(FRONT)
123 P0614123 COVER 192 P0614092 VISE PLATE
123-1 PS14M PHLP HD SCR M6-1 X 12 193 PFH23M FLAT HD SCR M8-1.25 X 16
124 P0614124 SWIVEL PLATE 194 PSS09M SET SCREW M8-1.25 X 20
126 PB01M HEX BOLT M10-1.5 X 30 195 PN03M HEX NUT M8-1.25
127 PN02M HEX NUT M10-1.5 196 P0614096 GIB
128 P0614128 FIXED PLATE 197 PW01M FLAT WASHER 8MM
129 PSB115M BUTTON HD CAP SCR M6-1 X 16 198 PSB14M CAP SCREW M8-1.25 X 20
130 PSB84M CAP SCREW M10-1.5 X 35 199 P0614099 LEADSCREW A
