Grizzly G0614 - Manual (Page 51)

G0613/14 Swivel Mast Metal Cutting Bandsaw
-49-
Parts List (G0613)
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PSB64M CAP SCREW M10-1.5 X 25 41 PSS06M SET SCREW M8-1.25 X 16
2 PW04M FLAT WASHER 10MM 43 P0613043 HANDLE
3 P0613003 SHAFT 44 P0613044 HANDLE PIPE
4 P0613004 ANCHOR BLOCK 45 PSBS05M BUTTON HD CAP SCR M6-1 X 25
5 PN13M HEX NUT M16-2 46 PSS20M SET SCREW M8-1.25 X 8
6 P6204 BALL BEARING 6204 47 PSB40M CAP SCREW M8-1.25 X 35
7 P0613007 BODY FRAME 48 P0613048 BLADE ADJUSTMENT BAR
8 PN01M HEX NUT M6-1 49 PSB58M CAP SCREW M8-1.25 X 12
9 PB29M HEX BOLT M6-1 X 30 50 PS09M PHLP HD SCR M5-.8 X 10
10 P0613010 KNOB 51 PW02M FLAT WASHER 5MM
11 P0613011 BLADE TENSION HANDLE 52 P0613052 BLADE COVER (FRONT)
12 P0613012 CONCAVE WASHER 53 P0613053 ADJUSTMENT BLOCK (FRONT)
13 P0613013 LEADSCREW 53-1 P0613053-1 FLOW VALVE
14 PSB31M CAP SCREW M8-1.25 X 25 53-2 P0613053-2 COOLANT HOSE
15 P0613015 FIXED BLOCK 53-3 P0613053-2 STEEL "T"
16 PSB13M CAP SCREW M8-1.25 X 30 54 P0613054 ECCENTRIC GUIDE (L)
17 PLW04M LOCK WASHER 8MM 55 P608A BALL BEARING 608
18 P0613018 REDUCER BLOCK 57 PR09M EXT RETAINING RING 20MM
19 PW01M FLAT WASHER 8MM 58 P0613058 ECCENTRIC GUIDE (R)
20 PSB31M CAP SCREW M8-1.25 X 25 62 PSB13M CAP SCREW M8-1.25 X 30
21 P0613021 GEARBOX 63 PW01M FLAT WASHER 8MM
22 P0613022 MOTOR 220V, SINGLE PHASE 64 P0613064 ADJUSTMENT BLOCK (REAR)
22-1 P0613022-1 START CAPACITOR 65 PSB40M CAP SCREW M8-1.25 X 35
22-2 P0613022-2 RUN CAPACITOR 66 P608A STEEL BALL
22-3 P0613022-3 FAN 67 P0613067 CHIP PLATE
22-4 P0613022-4 FAN COVER 68 PW02M FLAT WASHER 5MM
25 PB32M HEX BOLT M10-1.5 X 25 69 PS09M PHLP HD SCR M5-.8 X 10
26 PW04M FLAT WASHER 10MM 70 P0613070 DRIVE WHEEL
27 P0613027 KEY 8 X 7 X 35 71 PW04M FLAT WASHER 10MM
28 P0613028 OUTPUT SHAFT 72 PB32M HEX BOLT M10-1.5 X 25
29 PK109M KEY 7 X 7 X 35 73 P0613073 WATERPROOF LIMIT SWITCH
30 P6206 BALL BEARING 6206 73-1 P0613073-1 SWITCH BRACKET
31 P0613031 SPRING SUPPORT 73-2 PS09M PHLP HD SCR M5-.8 X 10
32 P0613032 TENSION SPRING 73-3 PS75M PHLP HD SCR M5-.8 X 35
33 PSB06M CAP SCREW M6-1 X 25 73-4 P0613073-4 WATERPROOF POWER CORD
34 PLW03M LOCK WASHER 6MM 74 P0613074 MAIN BLADE COVER
35 P0613035 FRAME PIVOT SHAFT 75 PW03M FLAT WASHER 6MM
36 P0613036 CHIP COVER 76 P0613076 KNOB SCREW M6-1 X 10
37 P0613037 TAPERED BEARING 32006 77 P0613077 SAW BLADE
38 P0613038 BLADE COVER(REAR) 78 P0613078 IDLER WHEEL
39 P0613039 KNOB BOLT 3/8-24 X 1 79 PR11M EXT RETAINING RING 25MM
40 P0613040 FIXED BLOCK
