G0613/14 Swivel Mast Metal Cutting Bandsaw
-3-
Machine Data Sheet
MODEL G0613 SWIVEL MAST METAL-CUTTING BANDSAW
Customer Service #: (570) 546-9663 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901
MACHINE DATA
SHEET
Product Dimensions:
Floor to Table Height .......................................................................................................................................... 35
5
⁄
8
"
Overall Dimensions ...................................................................................................................63"L x 29
3
⁄
4
"
W x 66
"
H
Approximate Net Weight ................................................................................................................................................ 418 lbs.
Shipping Dimensions:
Overall Dimensions (Crate 1, Machine) ...........................................................................26
1
⁄
2
"
L x 50
1
⁄
2
"
W x 34
9
⁄
16
"
H
Crate Dimensions (Crate 2, Cabinet) ............................................................................ 25
13
⁄
16
"
L x 6
3
⁄
8
"
W x 24
13
⁄
16
"
H
Type ...................................................................................................................................................Wood Slat Crate
Approximate Shipping Weight (Crate 1, Machine) .........................................................................................451 lbs.
Approximate Shipping Weight (Crate 2, Cabinet) ..........................................................................................59.5 lbs.
Electrical:
Controls .............................................................................................................. Centralized Control Panel Operation
Switch ......................................................................................................................................................... Pushbutton
Switch Voltage ............................................................................................................................................110V/220V
Recommended Cord Gauge ......................................................................................................... Three-Wire, 12 Ga.
Recommended Breaker Size ................................................................................................................................20 A
Motors:
Main
Type..................................................................................................................TEFC Capacitor Start Induction
Horsepower ................................................................................................................................................ 1 HP
Voltage (Prewired 110V)...................................................................................................................110V/220V
Phase ....................................................................................................................................................... Single
Amps .................................................................................................................................................15.4A/7.7A
Speed ................................................................................................................................................ 3450 RPM
Cycle .........................................................................................................................................................60 Hz
Number of Speeds ........................................................................................................................................... 1
Blade Drive ......................................................................................................................... Sealed Worm Gear
Bearings ...................................................................................................................... Shielded and Lubricated
Pump
Type.................................................................................................................. ................... Sealed/Waterproof
Horsepower ...............................................................................................................................................
1
⁄
8
HP
Voltage (Prewired 110V)...................................................................................................................110V/220V
Phase ....................................................................................................................................................... Single
Amps ...................................................................................................................................................4.5A/2.2A
Speed ................................................................................................................................................ 3450 RPM
Cycle .........................................................................................................................................................60 Hz
Bearings ...................................................................................................................... Shielded and Lubricated
