Grizzly G0516 User Manual
Page 59
G0516 Lathe/Mill
-57-
REF
PART #
DESCRIPTION
501
P0516501
HAND WHEEL
502
P0516502
OIL CUP 6MM
503
PK69M
KEY 4 X 4 X 12
504
P0516504
ROUND NUT
505
PS12M
PHLP HD SCR M3-.5 X 6
506
P0516506
OIL-STOPPING FELT
507
PS31M
PHLP HD SCR M6-1.0 X 35
508
P0516508
SADDLE LEADSCREW
509
P0516509
SADDLE
510
PS02M
PHLP HD SCR M4-.7 X 12
511
P0516511
CLEARANCE NUT
512
PS50M
PHLP HD SCR M3-.5 X 12
513
PN06M
HEX NUT M5-0.8
514
PS61M
PHLP HD SCR M5-.8 X 26
515
P0516515
PAD IRON GIB
516
P0516516
CROSS SLIDE
517
PS09M
PHLP HD SCR M5-.8 X 10
518
P0516518
CROSS SLIDE SPACER
519
PS39M
PHLP SCR M8-1.25 X 10
520
P0516520
GIB STRIP
521
P0516521
REAR-CLAMP PLATE
522
PS56M
PHLP HD SCR M4-.7 X 16
523
PS40M
PHLP HD SCR M5-.8 X 16
524
PN04M
HEX NUT M4-0.7
525
PS04M
PHLP SCR M8-1.25 X 20
526
PS06M
PHLP HD SCR M5-.8 X 20
527
P0516527
OIL-STOPPING FELT
528
P0516528
PROTECTING PANEL
529
P0516529
PROTECTING PANEL
530
P0516530
FRONT-CLAMP PLATE
531
P0516531
BRAKING PLATE
532
P0516532
LEADSCREW SUPPORT
533
PW03M
FLAT WASHER 6MM
534
P0516534
HANDLE BOLT
535
PB08M
HEX BOLT M6-1 X 20
536
P0516536
HANDLE SLEEVE
537
P8101
BEARING 8101
538
P0516538
SPRING PLATE
539
P0516539
INDEX RING
542
PRP58M
ROLL PIN 6 X 45
REF
PART #
DESCRIPTION
601
P0516601
HANDLE
602
PS03M
PHLP HD SCR M6-1 X 8
603
P0516603
COMPRESS SPRING
604
P0516604
STEEL BALL 5MM
605
P0516605
HANDLE SEAT
606
PS11M
PHLP HD SCR M6-1 X 16
607
PS38M
PHLP HD SCR M4-.7 X 10
608
P0516608
SHAFT SLEEVE
609
P0516609
APRON BODY
610
P0516610
HANDLE BOLT
611
P0516611
HANDLE SLEEVE
612
P0516612
HAND WHEEL
613
P0516613
SPRING PLATE
614
P0516614
INDEX RING
615
P0516615
SMALL SHAFT SLEEVE
616
P0516616
SPRING PIN 4X30
617
P0516617
SMALL GEAR SHAFT
618
P0516618
SHAFT SLEEVE
619
P0516619
GEAR
620
PS07M
PHLP HD SCR M4-.7 X 8
621
PK06M
KEY 5 X 5 X 10
622
P0516622
GEAR SHAFT
623
PS40M
PHLP HD SCR M5-.8 X 16
624
PRP20M
ROLL PIN 4 X 22
625
P0516625
HALF NUT BASE
626
PRP59M
ROLL PIN 5 X 12
627
PRP42M
ROLL PIN 3 X 20
628
P0516628
HALF NUT
629
P0516629
SLOTTED DISC
630
P0516630
ROTATING SHAFT
631
P0516631
SHAFT SLEEVE
632
P0516632
MOVING PLATE
633
PS07M
PHLP HD SCR M4-.7 X 8
634
P0516634
CARRIAGE FEED NOTICE
