-6-
g7947/g7948 12 speed Floor drill press
The information contained herein is deemed accurate as of 6/20/2010 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
PAGE 1 OF 2 Model G7948
MACHINE DATA
SHEET
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G7948 12 SPEED 20" FLOOR DRILL PRESS
Product Dimensions:
Weight.............................................................................................................................................................. 320 lbs.
Length/Width/Height.................................................................................................................34-3/4 x 21 x 70-3/4 in.
Foot Print (Length/Width)............................................................................................................................. 23 x 18 in.
Shipping Dimensions:
Type............................................................................................................................................................. Cardboard
Content............................................................................................................................................................ Machine
Weight.............................................................................................................................................................. 331 lbs.
Length/Width/Height............................................................................................................................. 60 x 26 x 13 in.
Electrical:
Minimum Circuit Size........................................................................................................................................ 20 amp
Switch.................................................................................................................. Paddle On/Off with Safety Lock Tab
Switch Voltage...................................................................................................................................................... 110V
Cord Length...................................................................................................................................................... 8-1/2 ft.
Cord Gauge....................................................................................................................................................16 gauge
Plug Included.......................................................................................................................................................... Yes
Motors:
Main
Type.................................................................................................................. TEFC Capacitor Start Induction
Horsepower...........................................................................................................................................1-1/2 HP
Voltage.................................................................................................................................................110/220V
Prewired......................................................................................................................................................110V
Phase........................................................................................................................................................Single
Amps.......................................................................................................................................................15/7.5A
Speed.................................................................................................................................................1725 RPM
Cycle..........................................................................................................................................................60 Hz
Number Of Speeds........................................................................................................................................... 1
Power Transfer ............................................................................................................................... V-Belt Drive
Bearings....................................................................................................................... Shielded and Lubricated
Main Specifications:
Construction
Table Construction...................................................................................................Precision Ground Cast Iron
Spindle Housing Construction.............................................................................................................. Cast Iron
Column Construction....................................................................................................Cylindrical Ground Steel
Head Construction................................................................................................................................Cast Iron
Base Construction................................................................................................................................ Cast Iron
Paint..........................................................................................................................................................Epoxy
Head Information
Head Swivel.......................................................................................................................................... 360 deg.
G7948 Machine Data Sheet
