g7947/g7948 12 speed Floor drill press
-49-
REF PART # DESCRIPTION REF PART # DESCRIPTION
92 P7943092 CHUCK KEY 108 P7947108 DP LIGHTS LABEL
93 P7947093 SWITCH BOX 109 P7947109 DRILL PRESS LABEL
94 P7943094 LIGHT BASE 110 P7947110 STRAIN RELIEF
94A PS06M PHLP HD SCR M5-.8 X 20 111 PR21M INT RETAINING RING 35MM
95 P7943093A LIGHT SOCKET 112 P7947112 DEGREE SCALE
96 P7943095 LIGHT DUST PLUG 113 P7947113 INDICATOR
97 PAW03M HEX WRENCH 3MM 114 PSS21M SET SCREW M8-1.25 X 25
98 PAW04M HEX WRENCH 4MM 115 PN03M HEX NUT M8-1.25
99 P7943103 DRIFT KEY 116 PLW10 LOCK WASHER 3/4
100 PWRCRD110L POWER CORD 110V, LONG 117 PN31M HEX NUT M12-1.5
100B P7947100B WIRE GASKET 118 PS05M PHLP HD SCR M5-.8 X 8
100C P7946100C MOTOR CORD 119 PW02M FLAT WASHER 5MM
102 G5715 SLEEVE MT#4/#3 120 P7948120 DEPTH STOP BRACKET
103 P7947103 MACHINE ID LABEL 121 P7948121 DEPTH STOP SCALE STUD
104 P7947104 MOTOR FAN COVER 122 PN03M HEX NUT M8-1.25
105 P7947105 SPEED CHART 123 P7948123 QUILL CLAMP
107 P7943107 GRIZZLY BLACK/AL LABEL 124 PCAP14M CAP SCREW M8-1.25 X 20
Safety labels warn about machine hazards and ways to prevent injury. the owner of this machine
MuSt maintain the original location and readability of the labels on the machine. If any label is
removed or becomes unreadable, REPLacE that label before using the machine again. contact
Grizzly at (800) 523-4777 or www.grizzly.com to order new labels.
