-44-
g7947/g7948 12 speed Floor drill press
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P7947001 BASE 47D PHTEK6M TAP SCREW M4 X 16
2 PB27M HEX BOLT M12-1.75 X 30 47E P7942020A YELLOW SWITCH KEY
3 P7947003 RACK 48 PS14M PHLP HD SCR M6-1 X 12
4V2 P7947004 COLUMN 7-1/4 IN V2.09.05 49 P7943049 CORD CLAMP
5 P7947005 TABLE BRACKET 50 P7947050 HEAD CASTING
6 P7948006 HANDLE ARM 51 PB03M HEX BOLT M8-1.25 X 16
6-1 P7943006 HANDLE 52 P7947052 SHIFTER
7 PSS01M SET SCREW M6-1 X 10 53 P7947053 LEFT SLIDE BAR
8 P7947008 SHAFT 54 P7947054 RIGHT SLIDE BAR
9 PN01M HEX NUT M6-1 55 P7947055 MOTOR BASE
10 P7947010 TABLE PIN 56 PW04M FLAT WASHER 10MM
11 PW13 FLAT WASHER 3/4 57 PN02M HEX NUT M10-1.5
12 P7947012 HEX BOLT M20-2.5 x 45 58 P7947058 MOTOR 1HP 1PH 110/220V
13 P7943013 TABLE BOLT M10-1.5 X 30 58-1 P7947058-1 MOTOR FAN
14 P7947014 TABLE ARM BRACKET 58-2 P7947058-2 CAPACITOR COVER
15 P7947015 TABLE 58-3 P7947058-3 S CAPACITOR 400M 250V
16 P7943016 CLAMP BOLT 58-4 P7947058-4 WIRING BOX COVER
17 P7947017 GEAR 14T 59 P7947059 MOTOR PULLEY
18 P7947018 WORM GEAR 60 PK23M KEY 5 X 5 X 25
19 P7947019 RACK RING 61 PSS01M SET SCREW M6-1 X 10
20 PRP04M ROLL PIN 4 X 24 62 PVA29 V-BELT A29
21 PSS01M SET SCREW M6-1.0 X 10 63 P7947063 CENTER SHAFT
22 P7947022 FEED SHAFT 65 P6202ZZ BALL BEARING 6202 ZZ
23 P7947023 SCALE RING 66 PR02M EXT RETAINING RING 14MM
24 PK07M KEY 6 X 6 X 20 67 P7947067 CENTER PULLEY
25 P7947025 HANDLE BODY 68 PW03M FLAT WASHER 6MM
26V2 P7947026 HANDLE V2.02.99 69 PS14M PHLP HD SCR M6-1 X 12
27V2 P7947027 KNOB M12-1.75 V2.02.99 70 PS09M PHLP HD SCR M5-.8 X 10
28 P7947028 FEED SHAFT CONNECTOR 71 PW02M FLAT WASHER 5MM
29 PB01M HEX BOLT M10-1.5 X 30 72 P7943072 PULLEY COVER KNOB
29A P7947029A PLASTIC LOCK CAP 73 P7947073 PULLEY HOUSING 8-1/4 X 28-1/2 IN
30 PSS09M SET SCREW M8-1.25 X 20 74 PVA31 V-BELT A31
31 P7947031 ROLL PIN 8 X 105 75 P7947075 PULLEY NUT
32 PR05M EXT RETAINING RING 15MM 76V2 P7947076 SPINDLE PULLEY V2.02.99
33 P7947033 SHIFTER BAR 77V2 P7947077 INSERT PULLEY V2.02.99
34 P7943034 SLIDE BAR BOLT M10-1.5 X 25 78 PR26M INT RETAINING RING 52MM
35 PB07M HEX BOLT M8-1.25 X 25 79 P6207ZZ BALL BEARING 6207 ZZ
36 PW01M FLAT WASHER 8MM 80 P7947080 SPACER
37 PN03M HEX NUT M8-1.25 81 P6207ZZ BALL BEARING 6207 ZZ
38 PN02M HEX NUT M10-1.5 82 PR37M EXT RETAINING RING 32MM
39 PSS13M SET SCREW M10-1.5 X 12 83 P7947083 SPANNER NUT
41 PN05M HEX NUT M16-1.5 84 P7947084 TAB WASHER 8107
42 P7947042 SPRING CAP 85 P6206ZZ BALL BEARING 6206 ZZ
43 P7947043 TORSION SPRING 86 P7947086 RUBBER WASHER
44 P7947044 SPRING COVER 87 P7947087 QUILL
45 PS08M PHLP HD SCR M5-.8 X 12 88 P6206ZZ BALL BEARING 6205 ZZ
46 P7943097 LIGHT SWITCH 89 P7947089 SPINDLE
47 G8988 GRIZZLY SAFETY PADDLE SWITCH 90V2 P7947090A ARBOR MT3-JT3 V2.03.02
47C P7947047C SWITCH PLATE 91 P7948091 CHUCK JT3 X 1-16MM
G7947 Parts List
