Creating an Ethernet network
■ Router Name and Domain Name - Check with your ISP to see if entries are required
in these fields and, if so, what entries are required. Normally, leaving the fields
blank will work.
■ LAN IP Address - We recommend that you accept the defaults.
■ WAN IP Address - If your ISP assigns you a different IP address each time you
log on, click Obtain an IP Address Automatically . If your ISP requires a fixed IP
address, click Specify an IP Address , then type the values provided by your ISP.
4
When you are finished entering information on the Setup page, click Apply .
5
Click the DHCP tab on the top of the screen.
6
Click the Enable checkbox, then click Apply .
7
Press the reset button on your cable or DSL modem, then restart the computer. Your
network should be running. Go to
“Testing your network” on page 82 .
