Installation of the Magnum CS14 & CSN14 Series Converter Switches is a
simple procedure. The installation location is dependent upon the physical layout of the
Ethernet network and associated cabling. Make sure the unit is installed in a location that is
easily accessible to an
AC power outlet or
power strip, and where
convection cooling is
not inhibited. The green
Power (PWR) Led must
turn ON, when power is
applied through the
internal DC input 12V,
24V or –48V DC or
external AC through 9V
DC jack.
