CS14 & CSN14 Series Converter Switches Installation and User Guide (09/09)
15
www GarrettCom com . .
smoke and insects, and is plenum rated. Choices of models for external AC or internal DC
power are available. Ambient operating temperature is –25°C to + 60°C. Storage
temperature rating is between –25°C to
+ 85°C depending on the power source
used.
Fig 2.2c CS14P with 100Mb SC
Connector
The red-label, Magnum
CS14P (as shown in Fig. 2.2c with
100Mb SC-fiber) a premium rated unit
suitable for temperature un-controlled
outdoor applications. Specially
designed with premium-grade extended
temperature components, the CS14P
uses similar thermal techniques to the CS14H hardened units for cooling. Mounting options
Fig 2.2c
