CS14 & CSN14 Series Converter Switches Installation and User Guide (09/09)
4
www GarrettCom com . .
Conformal Coating (optional) for Humidity protection
Note: H and P models are designed for NEBS compliance, including, vibration, shock and
altitude.
Packaging:
Enclosure: Rugged sheet metal (Steel).
Dimensions, Switch unit: Height x Width x Depth
3.5 in H x 3.0 in W x 1.0 in D (8.9 cm x 7.6 cm x 2.5 cm)
Weight: all models: 8 oz. (227g);
Power supply, –d, and i:
5.9 oz (170g)
–Hd, and Hi: 5.8 oz (165g)
–Pd, and =Pi: 7.9 oz (225g)
Cooling Method: Convection on regular model, plus the case is used as a heat sink
on “H” and “P” models.
