CS14 & CSN14 Series Converter Switches Installation and User Guide (09/09)
7
www GarrettCom com
.
.
Direct DC POWER SUPPLY: built-in terminal block
for +, -, ground along with 12VDC jack
12V DC internal (range of 8.0 to 15V DC)
24V DC internal (range of 18 to 36V DC)
-48V DC internal (range of 36 to 60V DC), -, ground
Power Consumption: 3 watts typical and 4 watts max. for all models
Note 1: 8-15V DC can be used for dual source DC input
Note 2: Internal DC power floats, user may ground “+” or “-” if desired.
Port Connectors:
RJ-45 Port: Auto-cross(MDIX), 100BASE-TX and 10BASE-T:shielded 8-pin
female. Three RJ-45 ports provided in front and one on the rear. Supports shielded
(STP) and unshielded (UTP) Cat 3,4,5 cable. For POE pass-through option on H
and P models, request quote.
