Page 15
12
The optional RMT-16IR remote control will allow the user to select which source
each of the 4 connected displays will be viewing at the source location. Each of the
4 displays are assigned a group of 4 buttons that correspond to the 4 source inputs.
Please use the information below when selecting the desired source for each display.
RMT-16IR Button
Display
Source
1
1
1
2
1
2
3
1
3
4
1
4
5
2
1
6
2
2
7
2
3
8
2
4
9
3
1
10
3
2
11
3
3
12
3
4
13
4
1
14
4
2
15
4
3
16
4
4
OPTIONAL RMT-16IR REMOTE DESCRIPTION
LED Indicator
LE
Input
Selection
Buttons
