Warning, Arts, Dentification – Genie 3681036666 User Manual
Page 12: Power head parts list, Iring, Iagram
1j
1X
1L
1N
1E
1K
1D
1A
1N
1N
1H
1B
1Q
1G
1D
1F
49
1P
1N
1M
12
For Help, call 1-800-35-GENIE or visit www.geniecompany.com
p
aRtS
i
DeNtifiCatioN
p
oweR
h
eaD
Power Head Assembly
[1]
Item Part Name
*
1
Power Head Assembly
1
*
1A Cover (by Series Model)
1
*
1B Front Panel Assembly
1
*
1D Motor Parts
1
*
1E Circuit Board Assembly
1
*
1F Capacitor (By Series/Model)
1
*
1G Opto Wheel (not shown)
1
*
1H Carriage Slide
1
*
1J Chain
1
*
1K Circuit Board Bracket
1
*
1L Drive Module
1
*
1M Terminal Strip
1
*
1N No . 8-32 x 3/4” Hex Head Screw
w / int . Lockwasher
1
*
1P Shock Absorption Stop
1
*
1Q Motor Mount Bracket (not shown)
1
*
1X Chassis
1
4
1/4-20 Shoulder Bolt
1
5
1/4” Flange Nut
1
39 Coupler
1
41 No . 8-32 x 3/8” Phillips
Hex Head Screw
1
42 No . 8-32 x 3/8” Phillips
Pan Head Screw
1
48 Mounting Straps
2
49 Light Lens
1
Power Head Parts List
Number
Included
* Pre-assembled
w
iRiNG
D
iaGRam
WARNING
Shut off power before opening the Cover .
Components inside Cover May Cause Electric Shock
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
MOTOR
MOTOR
CAPACITOR
THERMAL
PROTECTOR
POWER CORD
SEQUENCER HOUSING
LIGHT
RED
RED
ORANGE
ORANGE
YELLOW
YELLOW
YELLOW
BLACK
DOWN
UP
WHITE
BLUE
GREE
N
GREE
N
WHIT
E
BL
A
C
K
POWER HEAD TERMINALS
