53
4 Open the card retention lever.
5 Remove the old expansion card. You can slightly seesaw
the card end-to-end to loosen the card, but do not bend
the card sideways.
6 Install the new card into the expansion slot. You can
slightly seesaw the card end-to-end to help insert the
card, but do not bend the card sideways.
7 If you have just replaced an expansion card, reconnect
the expansion card cables (if any) using your notes from
Step 3 . If you have added a new expansion card,
connect its cables according to its user guide.
8 Replace the side panel by following the instructions in
“Replacing the side panel” on page 33 .
Caution
Do not touch the contacts on the bottom part of the expansion
card. Touching the contacts can cause electrostatic damage to the card.
Card retention lever
