Gold's Gym GR 7000 GGBE6974.1 - Manual (Page 5)

5
M6 Washer (86)
M8 Washer (94)
M10 Split Washer (93)
M8 Nylon Locknut (78)
M10 Washer (84)
M10 Nylon Locknut (79)
M6 Nylon Locknut (80)
M10 x 65mm Carriage Bolt (83)
M10 x 42mm Button Bolt (96)
M8 x 42mm Hex Bolt (130)
M6 x 64mm Screw (89)
M
M10 Large Washer (76)
M10 x 62mm Button Bolt (88)
M10 x 67mm Button Bolt (90)
M10 x 53mm Button Bolt (147)
M10 x 46mm Button Bolt (100)
M10 x 49mm Button Bolt (104)
M10 x 25mm Button Screw (98)
M
1
0
x
1
8
0
m
m
B
u
tt
o
n
B
o
lt
(1
4
5
)
PART IDENTIFICATION CHART
Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART LIST in the center of this manual.
Note: Some small parts
may have been preattached. If a part is not in the hardware kits, check to see if it has been preattached.
