2
308–287
Table of Contents
Warnings 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation 6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance 7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting 8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service 9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parts 11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dimensions 15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Technical Data 15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warranty 16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Graco Phone Number 16 . . . . . . . . . . . . . . . . . . . . . . . . . .
Symbols
Warning Symbol
WARNING
This symbol alerts you to the possibility of serious
injury or death if you do not follow the instructions.
Caution Symbol
CAUTION
This symbol alerts you to the possibility of damage to
or destruction of equipment if you do not follow the
corresponding instructions.
WARNING
INJECTION HAZARD
Spray from hose leaks or ruptured components can inject fluid into your body and cause an extremely
serious injury, including the need for amputation. Splashing fluid in the eyes or on the skin can also
cause a serious injury.
D
Fluid injected into the skin might look like just a cut, but it is a serious injury. Get immediate medi-
cal attention.
D Do not stop or deflect fluid leaks with your hand, body, glove, or rag.
D Follow the Pressure Relief Procedure on page 6 whenever you: are instructed to relieve pres-
sure; stop operation, or clean, check, or service the equipment; and install or clean the spray tip.
D
Tighten all the fluid connections before operating the equipment.
D
Check the hoses, tubes, and couplings daily. Replace worn, damaged, or loose parts immediately.
Permanently coupled hoses cannot be repaired; replace the entire hose.
FIRE, EXPLOSION, AND ELECTRIC SHOCK HAZARD
D This equipment must only be installed by trained and qualified personnel.
D The meter’s electrical chassis must be properly grounded. See Check the Electrical Grounding
on page 5.
D
Do not allow water or other liquids to spill on the electrical chassis.
D
Do not immerse the chassis in fluids.
D
The air line to the electrical chassis must be turned OFF and the pressure relieved before servicing
or flushing the meter.
