Graco Inc. 308287 User Manual
Pro t pulse electronic volumetric flow meter, Instructions-parts list

308–287
Rev. C
Supersedes Rev. B
and PCN C
First choice when
quality counts.
t
01847
INSTRUCTIONS-PARTS LIST
INSTRUCTIONS
This manual contains important
warnings and information.
READ AND KEEP FOR REFERENCE.
PRO
t
Pulse
Electronic Volumetric Flow Meter
For use with Plural Component Precision Mixing Systems
This meter is designed to be used in a Class I, Group D hazardous environment
2800 psi (19.6 MPa, 196 bar) Maximum Working Fluid Pressure
50 psi (350 kPa, 3.5 bar) Maximum Working AirPressure
Part No. 235–402, Series A
Flow Meter with 0.1 cc per tooth fluid volume flow
Model 235–403, Series A
Flow Meter with 0.4 cc per tooth fluid volume flow
NOTE: See the Accessories section to order Fiber-
Optic Cables and to order the Fluid Manifold.
U.S. and Foreign Patents Pending
GRACO INC.
P.O. BOX 1441
MINNEAPOLIS, MN
55440–1441
E
COPYRIGHT 1993, GRACO INC.
Graco Inc. is registered to I.S. EN ISO 9001
