Graco Inc. 224200 User Manual

Model pro 4500sc t electrostatic air spray gun, Instructions-parts list

308131

Rev. R

0365

Part No. 224200 shown

NOTE: Any modification of genuine Graco parts or replacement of parts with non-Graco parts will void agency approvals.

U.S. PATENT NO. 4,290,091; 4,219,865; 4,497,447; 4,462,061; 4,660,774; 5,063,350; 5,080,289; D350,387
Patented 1986, 1987 Canada
Brevete 1986, 1987
U.K. PATENT NO. 2,147,158; 2,142,559B; 2,140,327B; 2,245,197B
Other U.S. and Foreign Patents Pending

INSTRUCTIONS-PARTS LIST

INSTRUCTIONS

This manual contains important
warnings and information.
READ AND KEEP FOR REFERENCE.

Model PRO 4500sc

Electrostatic Air Spray Gun

85 kV, MANUAL GUN

100 psi (7 bar, 0.7 MPa) Maximum Working Pressure

For use with Class

, Group D paint spray materials

Part No. 224200, Series B
Air Spray Gun with two-finger trigger

With 0.059 in. (1.5 mm) spray nozzle

Part No. 224400, Series B
Air Spray Gun with four-finger trigger

With 0.059 in. (1.5 mm) spray nozzle

GRACO INC.

P.O. BOX 1441

MINNEAPOLIS, MN

55440–1441

Graco Inc. is registered to I.S. EN ISO 9001

This manual is related to the following products:

224400
