-32-
model g1071 (mfg. 1/02+)
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P1071001 TABLE 72 PSW06 PADDLE SWITCH 110/220V WITH KEY
2 P1071002 INSERT 1-3/4 X 2-3/16 73 P1071073 SWITCH-MOTOR CORD
3 P1071003 INSERT 2-3/16 X 3-1/2 74 P1071074 POWER CORD
4 P1071004 BRACKET 75 P1071075 STRAIN RELIEF
5 P1071005 TRUNNION 76 P1071076 MOTOR
6 P1071006 INNER TRUNNION 80 PB24 HEX BOLT 3/8-16 X 1-1/4
7 P1071007 DUST HOOD 81 PB18 HEX BOLT 3/8-16 X 1
8 P1071008 HOUSING CASTING 82V2 PLW06M LOCK WASHER 10MM
8-1 P1071008-1 RUBBER STRIP 83 PSS10 SET SCREW 1/4-20 X 5/8
9 P1071009 DIP STICK 84V2 PRP27M ROLL PIN 5 X 28
10 P1071010 SPINDLE CASTING 85 PW02 FLAT WASHER 3/8
11 P1071011 COVER 86 PN02 HEX NUT 5/16-18
12 P1071012 SPINDLE 87V2 PS41 PHLP HD SCR #6-32 X 1/4
13 P1071013 SPECIAL KEY 5 X 5 X 50 88V2 PB24 HEX BOLT 3/8-16 X 1-1/4
14 P1071014 JAM NUT 15/16-20 89 PN08 HEX NUT 3/8-16
15 P1071015 SPANNER NUT 15/16-20 90 PCAP03 CAP SCREW 5/16-18 X 1
16 P1071016 WORM 91 PLW01 LOCK WASHER 5/16
17 P1071017 MOUNTING BRACKET 92V2 PCAP14 CAP SCREW 3/8-16 X 1
18 P1071018 BEARING BLOCK 93 PCAP16 CAP SCREW 3/8-16 X 3/4
19 P1071019 WORM GEAR 24T 94 P6206 BALL BEARING 6206ZZ
20 P1071020 CONNECTING ROD 95 P1071095 SEAL 30-62-8
21 P1071021 WRIST PIN 96 PR38M INT RETAINING RING 62MM
22 P1071022 DRIVE SHAFT 97 P6205ZZ BALL BEARING 6205ZZ
23 P1071023 HUB 98V2 P1071098V2 CAP SCREW #4-40 X 1/2 V2.01.02
24 P1071024 CENTER BLOCK 99 PRP05M ROLL PIN 5 X 30
25B P1071025B CASE V2.11.98 100V2 PK23M KEY 5 X 5 X 25
35 P1071035 GUIDE SHAFT 101V2 PSS02 SET SCREW 5/16-18 X 3/8
54 P1071054 HEX BOLT 3/8-16 X 6-1/2 102 P1126153 OIL DRAIN PLUG
55 PZERK2 GREASE FITTING M6-1 x 5 103 PN04 HEX NUT 5/8-11
61 P1071061 POINTER MOUNT 104 PLW06 LOCK WASHER 5/8
62 P1071062 CABINET 107 PB03 HEX BOLT 5/16-18 X 1
65 P1071065 DOOR 108 PWF01 FENDER WASHER 5/16
66 P1071066 LOCK HANDLE 112 PS01 PHLP HD SCR 10-24 X 1/2
67 P1071067 SCALE 113 PN07 HEX NUT 10-24
68 P1183108 RIVET 114 PCAP03 CAP SCREW 5/16-18 X 1
69 P1071069 OIL BREATHER 118 P1071118 INSERT 4-1/4 x 6
70 P1071070 KNOB 119 P1071119 SWITCH DUST COVER
71 P1071071 GASKET 121 PK22M KEY 5 x 5 x 24
Main Parts List
