-4-

Model g8688 (Mfg. 3/09+)

The information contained herein is deemed accurate as of 6/11/2012 and represents our most recent product specifications.

Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.

PAGE 1 OF 3

Model G8688

MACHINE DATA

SHEET

Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901

MODEL G8688 7" X 12" MINI METAL LATHE

Product Dimensions:

Weight................................................................................................................................................................ 75 lbs.

Width (side-to-side) x Depth (front-to-back) x Height............................................................... 27-3/4 x 11-1/2 x 12 in.

Footprint (Length x Width)................................................................................................................. 27-3/4 x 8-3/4 in.

Shipping Dimensions:

Type............................................................................................................................................................. Cardboard

Content........................................................................................................................................................... Machine

Weight................................................................................................................................................................ 90 lbs.

Length x Width x Height....................................................................................................................... 30 x 13 x 13 in.

Electrical:

Minimum Circuit Size........................................................................................................................................ 10 amp

Switch............................................................................................................................................... Forward/Reverse

Switch Voltage..................................................................................................................................................... 110V

Cord Length............................................................................................................................................................ 6 ft.

Cord Gauge................................................................................................................................................... 14 gauge

Plug Included.......................................................................................................................................................... Yes

Motors:

Main

Type.......................................................................................................................................... Universal Brush

Horsepower............................................................................................................................................. 3/4 HP

Voltage....................................................................................................................................................... 110V

Prewired..................................................................................................................................................... 110V

Phase....................................................................................................................................................... Single

Amps.............................................................................................................................................................. 3A

Speed........................................................................................................................................... Variable RPM

Cycle......................................................................................................................................................... 60 Hz

Number of Speeds................................................................................................................................ Variable

Power Transfer ..................................................................................................................... Belt Drive to Gear

Bearings................................................................................................. Shielded and Permanently Lubricated

Main Specifications:

Operation Info

Swing Over Bed........................................................................................................................................... 7 in.

Distance Between Centers........................................................................................................................ 12 in.

Swing Over Cross Slide......................................................................................................................... 2-1/8 in.

Swing Over Saddle...................................................................................................................................... 5 in.

Swing Over Gap.......................................................................................................................................... 7 in.

Maximum Tool Bit Size........................................................................................................................... 5/16 in.

Compound Travel.................................................................................................................................. 2-3/4 in.

Carriage Travel.................................................................................................................................... 10-1/2 in.

Cross Slide Travel................................................................................................................................. 2-3/4 in.
