Grizzly G8688 - Manual (Page 42)

-40-
Model g8688 (Mfg. 3/09+)
parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
102 PSB50M CAP SCREW M5-.8 X 10 151 P8688151 COVER
105 P8688105 COMPOUND REST 152 P8688152 RUBBER PIPE
106 PSS35M SET SCREW M4-.7 X 14 153 P8688153 REAR SPLASH GUARD
107 P8688107 GIB STRIP 154 P8688154 F/N/R LABEL
108 P8688108 COMPOUND REST 155 P8688155 H/L LABEL
109 P8688109 POSITIONING PIN 156 P8688156 WARNING LABEL
110 PSB06M CAP SCREW M6-1 X 25 157 P8688157 GEAR 30T
111 P8688111 CLAMPING LEVER 158 P8688158 GEAR 35T
112 P8688112 TOOL REST 159 P8688159 GEAR 40T
113 P8688113 STUD M10-1.5 X 65 160 P8688160 GEAR 45T
114 P8688114 CROSS FEEDING SCREW 161 P8688161 GEAR 50T
115 P8688115 BRACKET 162 P8688162 GEAR 55T
116 PSB23M CAP SCREW M4-.7 X 12 163 P8688163 GEAR 57T
119 P8688119 SPECIAL NUT M18 164 P8688164 GEAR 60T
120 P8688120 MACHINE ID LABEL 165 P8688165 GEAR 65T
121 P8688121 GEAR CHANGE WARNING LABEL 166 P8688166 EXTERNAL JAWS (SET)
122 P8688122 SWITCH LABEL 167 P8688167 3 JAW CHUCK KEY
123 P8688123 CONTROL BOX 168 P8688168 RUBBER PAD
124 P8688124 PLUG W/CORD 169 P8688169 BRACING
125 P8688125 RUBBER FOOT 170 P8688170 FLAT HD SCR M3-.5 X 5
126 P8688126 CHIP TRAY 171 P8688171 CLAMP BLOCK
127 P8688127 BRACKET 172 PR36M EXT RETAINING RING 7MM
128 PK52M KEY 3 X 3 X 15 173 PS09M PHLP HD SCR M5-.8 X 10
129 P8688129 LEAD SCREW 174 P8688174 PROTECTOR
130 P8688130 INDICATOR TABLE LABEL 175 PSB50M CAP SCREW M5-.8 X 10
131 P8688131 BRACKET 176 PN01M HEX NUT M6-1
133 PSB56M CAP SCREW M3-.5 X 10 177 PSB06M CAP SCREW M6-1 X 25
134 P8688134 RACK 178 P05161137 E-STOP SWITCH
135 P8688135 CLAMP PLATE 179 P8689136 FUSE BOX
136 PW04M FLAT WASHER 10MM 180 P8689134 SPEED CONTROL KNOB
137 PSS34M SET SCREW M5-.8 X 16 181 P8688181 F/O/R SWITCH
138 P8688138 TAILSTOCK CASTING 182V2 P8688182V2 PC BOARD 3 TERMINALS V2.09.08
139 P8688139 TAILSTOCK SCREW 183 P8688183 ELECTRIC FILTER
140 P8688140 BRACKET 200 P8688200 OIL CAN
141 PSB17M CAP SCREW M4-.7 X 10 201 P8688201 HEX WRENCH SET
142 P8688142 TAILSTOCK QUILT 202 PWR810 WRENCH 8 X 10
143 P8688143 CENTER 203 PWR1417 WRENCH 14 X 17
144 P8688144 STUD M8-1.25 X 40 204V2 P8688204V2 FUSE 4A V2.06.07
145 P8688145 CLAMP 205 P8688205 FACE PLATE
146 P8688146 HANDLE 206 P8688206 STEADY REST
148 P8688148 PULLEY 207 P8688207 LATHE DOG
150 P8688150 MOTOR 208 P8688208 MOTOR BRUSH
safety labels warn about machine hazards and ways to prevent injury. The owner of this machine
MusT maintain the original location and readability of the labels on the machine. If any label is
removed or becomes unreadable, rEpLAcE that label before using the machine again. contact
Grizzly at (800) 523-4777 or www.grizzly.com to order new labels.
