Model g8688 (Mfg. 3/09+)
-39-
parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P8688001 BED WAY 52 PSB68M CAP SCREW M6-1 X 8
2 P8688002 3 JAW CHUCK 53 P8688053 COVER
3 P8688003 SPINDLE 54 PSB108M CAP SCREW M5-.8 X 45
4 PSS12M SET SCREW M6-1 x 25 55 P8688055 THREADS CUTTING CHART
6 PN01M HEX NUT M6-1 56 PSB03M CAP SCREW M5-.8 X 8
7 PK02M KEY 5 X 5 X 40 57 PW05M FLAT WASHER 4MM
8 PK29M KEY 4 X 4 X 8 58 P8688058 BUSHING W/KEY (2PC)
9 PSB33M CAP SCREW M5-.8 X 12 59 P8688059 GEAR 80T
10 P8688010 COVER 60 P8688060 SHAFT
11 P6206ZZ BALL BEARING 6206ZZ 61 P8688061 SUPPORT PLATE
12 P8688012 SPACER 62 PW01M FLAT WASHER 8MM
13 P8688013 HEADSTOCK CASTING 63 PN03M HEX NUT M8-1.25
14 P8689080 TRANSMISSION GEAR 64 P8688064 SHAFT
15 P8688015 SPACER 65 P8688065 DIAL
16 P8688016 SPUR GEAR 45T 66 P8688066 SHAFT 16T
17 P8688017 NUT M27 X 1.5 67 PSB24M CAP SCREW M5-.8 X 16
18 PSS31M SET SCREW M5-.8 X 8 68 P8688068 DIAL INDICATOR BODY
19 P0516604 STEEL BALL 5MM 69 PSS23M SET SCREW M4-.7 X 10
20 P8688020 COMPRESSION SPRING 4.9 X 9 70 P8688070 APRON
21 PSS02M SET SCREW M6-1 X 6 71 P8688071 GIB STRIP
22 PR03M EXT RETAINING RING 12MM 72 PW05M FLAT WASHER 4MM
23 P8688023 BALL BEARING 73 PSB18M CAP SCREW M4-.7 X 8
24 P8688024 H/L GEAR 12T/20T 74 P8688074 SHAFT
25 PK71M KEY 4 X 4 X 45 75 P8688075 HALF NUT BASE
26 P8688026 H/L GEAR SHAFT 76 P8688076 ANGLE BLOCK
27 P8688027 PULLEY 77 PFH19M FLAT HD SCR M4-.7 X 10
28 PR01M EXT RETAINING RING 10MM 78 P8688078 GROOVE CAM
29 P8688029 TIMING BELT LX136 79 P8688079 HANDLE
30 P8689141 BAR 80 P8688080 SHAFT
31 P8688031 SHIFTING ARM 81 P8688081 FEEDING GEAR (A) 11T/54T
32 P8688032 SHIFTING KNOB 82 P8688082 FEEDING GEAR (B) 24T
33 P8688033 SHIFTING LEVER 83 PSS01M SET SCREW M6-1 X 10
34 P8688034 SHIFTING GRIP 84 P8688084 WHEEL
35 P8688035 HANDLE 85 P8688085 HANDWHEEL HANDLE
36 P8688036 HANDLE MOUNT 86 P8688086 HANDLE, LARGE
37 P8688037 COMPRESSION SPRING 87 P8688087 DIAL
38 P8688038 INDICATOR 88 P8688088 BRACKET
39 P8688039 PINION 25T 89 P8688089 FEED SCREW
40 P8688040 SUPPORT SCREW 90 PN06M HEX NUT M5-.8
41 P8688041 PINION 20T 91 PSB26M CAP SCREW M6-1 X 12
42 P8688042 FIXED COVER 92 P8688092 SLIDE PLATE
43 PSB02M CAP SCREW M6-1 X 20 93 P8688093 SADDLE
44 PSB03M CAP SCREW M5-.8 X 8 94 P8688094 GIB STRIP
45 P8688045 GEAR 45T 95 P8688095 FEEDING NUT
46 P8688046 SHAFT 96 P8688096 SWIVEL DISK
47 PK03M KEY 3 X 3 X 8 97 PSB14M CAP SCREW M8-1.25 X 20
48 P8688048 MOUNT 98 PN04M HEX NUT M4-.7
49 PSB53M CAP SCREW M5-.8 X 18 99 PSS35M SET SCREW M4-.7 X 16
50 P8688050 PINION 20T 100 P8688100 CROSS SLIDE
