Grandstream Networks HT496 - Manual (Page 8)

Grandstream Networks, Inc. HT496 User Manual Page 8 of 29
Firmware 1.0.3.86 Last Updated: 7/2007
T ABLE 3: HT496 Hardware Specifications
LAN Interface 1 x RJ45 10 Mbps
WAN Interface 1 x RJ45 10 Mbps
FXS phone port 2 x FXS
Button 1
LED Green and red / solid state & blinking state
Universal
Switching
Power Adaptor
Input: 100-240VAC 50-60 Hz
Output: +5VDC, 1200mA
UL certified
Dimension 70mm (W) x 130mm (D) x 27mm (H)
Weight 0.6lbs (0.3kg)
Temperature 40 - 130
º
F / 5 45ºC
Humidity 10% - 90% (non-condensing)
Compliance FCC/CE/C-Tick
