Grandstream Networks, Inc.

HT496 User Manual

Page 27 of 29

Firmware 1.0.3.86

Last Updated: 7/2007

S

OFTWARE

U

PGRADE

Software upgrade can be done via either TFTP or HTTP. The corresponding configuration settings are in
the ADVANCED SETTINGS configuration page.

F

IRMWARE

U

PGRADE THROUGH

TFTP/HTTP

To upgrade via TFTP or HTTP, the “Firmware Upgrade and Provisioning upgrade via” field needs to be
set to TFTP or HTTP, respectively. “Firmware Server Path” needs to be set to a valid URL of a TFTP or
HTTP server, server name can be in either FQDN or IP address format. Here are examples of some valid
URL.
e.g. firmware.mycompany.com:6688/Grandstream/1.0.3.86
e.g. 168.75.215.190

NOTES:

• TFTP server in IP address format can be configured via IVR. Please refer to section

CONFIGURATION GUIDE for instructions. If TFTP server is in FQDN format, it must be set via
web configuration interface.

• End users recommended using our TFTP server. Its address can be found at

http://grandstream.com/y-firmware.htm

. Currently, the TFTP server, your HT496 can be upgraded

from has an IP address 168.75.215.190. For companies, we recommend to maintain their own
TFTP/ HTTP server for upgrade and provisioning procedures.

• Once a “Firmware Server Path” is set, user needs to update the settings and reboot the device. If

the configured firmware server is found and a new code image is available, the HT ATA will
attempt to retrieve the new image files by downloading them into the HT ATA’s SRAM. During
this stage, the HT ATA’s LEDs will blink until the checking/downloading process is completed.
Upon verification of checksum, the new code image will then be saved into the Flash. If
TFTP/HTTP fails for any reason (e.g., TFTP/HTTP server is not responding, there are no code
image files available for upgrade, or checksum test fails, etc), the HT ATA will stop the
TFTP/HTTP process and simply boot using the existing code image in the flash.

• Firmware upgrade may take as long as 1 to 20 minutes over Internet, or around 20 seconds if

performed on a LAN. We recommend that firmware upgrades be completed in a controlled LAN
environment if possible. For users who do not have a local firmware upgrade server,
Grandstream provides a NAT-friendly TFTP server on the public Internet for firmware upgrade.
Please check the Services section of Grandstream’s Web site to obtain our public TFTP server’s
IP address.

• Alternatively, user can download a free TFTP or HTTP server and conduct local firmware

upgrade. A free windows version TFTP server is available for download from

http://support.solarwinds.net/updates/New-customerFree.cfm

. The latest official release is

available @

http://www.grandstream.com/y-firmware.html

.

• User can also choose to download the free HTTP server from

http://httpd.apache.org/

or use

Microsoft IIS web server.


Directions to download a free TFTP Server:

1. Unzip the file and put all of them under the root directory of the TFTP server.
2. Put the PC running the TFTP server and the HT496 device in the same LAN segment.
3. Please go to File -> Configure -> Security to change the TFTP server's default setting from

"Receive Only" to "Transmit Only" for the firmware upgrade.

4. Start the TFTP server, in the phone’s web configuration page
5. Configure the Firmware Server Path with the IP address of the PC
6. Update the change and reboot the unit
