Grandstream Networks, Inc. HT496 User Manual Page 20 of 29
Firmware 1.0.3.86 Last Updated: 7/2007
T ABLE 8: HT496 Device Status Page Definitions
MAC Address The device ID in HEX format. This is needed for ISP troubleshooting.
WAN IP Address Shows WAN IP address of HT496.
Product Model Contains the product model info.
Software Version Program: This is the main software release. Boot and Loader are seldom changed.
System Up Time Shows system up time since the last reboot.
Registered Indicates whether the HT496 is registered to the service provider’s server.
PPPoE Link Up Indicates whether the PPPoE connection is up if the HT496is connected to DSL
modem.
NAT Indicates the type of NAT the HT496 is connected to via its WAN port. Based on
STUN protocol.
A DVANCED U SER C ONFIGURATION
Log in to the advanced user configuration page the same way as for the basic configuration page. The
password is case sensitive and the factory default password for Advanced User is “admin”.
Advanced User configuration includes the end user configuration and the advanced configurations
including: a) SIP configuration, b) Codec selection, c) NAT Traversal Setting and d) other miscellaneous
configuration. HT496 each FXS SIP account has its own configuration page. Their configurations are
identical.
