Grandstream Networks, Inc.

HT496 User Manual

Page 14 of 29

Firmware 1.0.3.86

Last Updated: 7/2007

LED

L

IGHT

P

ATTERN

I

NDICATION

Following tables show the LED light pattern indication. The LED shows PHONE1 status only.

T

ABLE

6: HT496 LED Definitions

RED

LED always indicates not

normal status

Button flashes every 2 seconds.
(if DHCP is configured)

DHCP Failed or WAN No Cable

Button flashes every 2 seconds.
(if SIP server is configured)

HT496 fails to register

Button flashes every 2 seconds.

Firmware Upgrading

Red light steady.

Device Malfunctions


GREEN

LED mostly indicates normal

working status

Button flashes every 2 seconds.

Message Waiting Indication

Button flashes at 1/10 second.

RINGING

Button flashes every second.

RINGING INTERVAL

Green light steady.

In Conversation
