Mill Head Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P4791001 SPANNER NUT M30-1.5 46 P4791046 ROLLING BEARING 109
2 P4791002 BEVEL GEAR 46T 47 PR56M EXT RETAINING RING 45MM
3 P4791003 SPACER 48 P4791048 MILL SPINDLE
4 P8107 THRUST BEARING 8107 48-1 P4791048-1 DRAW BAR
5 P4791005 LEADSCREW NUT BRACKET 49 P4791049 MILL DRIVE SYSTEM BASE
6 PSB13M CAP SCREW M8-1.25 X 30 50 P4791050 ROLLING BEARING 204
7 P4791007 ELEVATION LEADSCREW NUT 51 P4791051 SPACER
8 PK60M KEY 8 X 8 X 15 52 P4791052 BUSHING
9 P4791009 MILL COLUMN 53 P4791050 ROLLING BEARING 204
10 P4791010 CAP SCREW M16-2 X 35 54 P4791054 THREADED SHAFT
11 P4791011 MILL HEADSTOCK CASTING 55 PN43M ACORN NUT M10-1.5
12 P4791012 LOCK PLUNGER 56 P4791056 IDLER PULLEY
13 P4791013 SPECIAL HEX NUT 57 P4791057 SPINDLE PULLEY
14 P4791014 ELEVATION LEADSCREW 58 P4791058 MILL DRIVE SYSTEM COVER
15 P8108 THRUST BEARING 8108 59 P4791059 SPINDLE CAP BASE
16 P4791016 LOCK COLLAR M36-1.5 60 P4791060 SPINDLE CAP
17 PS05M PHLP HD SCR M5-.8 x 8 61 P4791061 PULLEY CAP
18 P4791018 MILL COLUMN BRACKET 62 PSS14M SET SCREW M8-1.25 X 12
19 PSB31M CAP SCREW M8-1.25 X 25 63 PW04M FLAT WASHER 10MM
20 PR07M EXT RETAINING RING 18MM 64 P4791064 LOCK PLUNGER CAP
21 P4791021 BUSHING 65 P4791065 HANDLE M10-1.25 X 50
22 P4791022 COLUMN COVER 66 PSB76M CAP SCREW M8-1.25 X 18
23 P4791023 LONG KNOB B8 X 40 67 P4791067 LOCK BOLT M10 X 50
24 P4791024 HANDLE M8-1.25 X 40 68 PSS06M SET SCREW M8-1.25 X 16
25 P4791025 HANDLE HUB 69 P4791069 SWITCH PANEL
26 P4791026 LOCK BOLT 70 PSS41M SET SCREW M8-1.25 X 18
27 P4791027 LOCK BOLT SLEEVE 71 PS52M PHLP HD SCR M4-.7 X 20
28 P4791028 TAPER PIN 4 X 28 72 PS09M PHLP HD SCR M5-.8 X 10
29 P4791029 GEAR SHAFT BRACKET 74 P4791074 MILL SWITCH ASSEMBLY
30 P4791030 BEVEL GEAR SHAFT 30T 74-1 P479174-1 ELECTRICAL BOX
31 PB08M HEX BOLT M6-1 X 20 74-2 P479174-2 SWITCH COVER
32 PSS17M SET SCREW M8-1.25 X 6 74-3 PS36 PHLP HD SCR 10-24 X 2-1/2
33 PR09M EXT RETAINING RING 20MM 74-4 P479174-4 FWD/REV SWITCH
34 P4791034 BUSHING 74-5 P479174-5 ON SWITCH
35 P4791035 CAM SHAFT 74-6 P479174-6 OFF SWITCH
36 P4791036 BEARING CAP 74-7 P4791941 STRAIN RELIEF
37 PSS07M SET SCREW M5-.8 X 5 75 PEC08M E-CLIP 16MM
38 P4791038 FELT COLLAR 76 P4791076 LOCK BOLT SLEEVE
39 P4791039 TAPERED ROLLER BEARING 7108 77 P4791077 LOCK BOLT PLUNGER
40 P4791040 MILL QUILL 78 P4791078 HANDLE KNOB
41 P4791041 TAPERED ROLLER BEARING 7107 79 P4791079 HANDLE HUB
42 P4791042 SPANNER LOCK WASHER 35MM 80 P4791080 SPECIAL SLOTTED SCREW
43 P4791043 SPANNER NUT M35-1.5 81 PVM37 V-BELT 3L370
44 P4791044 BEARING CAP 82 PVM50 V-BELT 3L500
45 PB148M HEX BOLT M5-.8 X 16
