1–2 MULTILINK ML2400 ETHERNET COMMUNICATIONS SWITCH – INSTRUCTION MANUAL
INTRODUCTION CHAPTER 1: INTRODUCTION
1.2 Ordering
1.2.1 Order Codes
The following table illustrates the order codes for the MultiLink ML2400 Ethernet Switch.
The fiber optic LC ports are limited to a total of 12.
Note Please refer to the GE Digital Energy website and Online Store for a complete list of
modules and options
ML2400 – * – * – * – * – * – * – *
Module A B C D |
Base ML2400 | | | | | | | | MultiLink ML2400 Ethernet Switch
Port mounting F | | | | | | | Front-mounted ports
B | | | | | | | Rear-mounted ports
Power supply AC | | | | | | 100 to 240 V AC power supply
HI | | | | | | 88 to 300 V DC / 85 to 265 V AC
LO | | | | | | 36 to 70 V DC
Redundant power
supply
XX | | | | | No redundant power supply
HI | | | | | 88 to 300 V DC / 85 to 265 V AC power supply
LO | | | | | 36 to 70 V DC power supply
Modules A1 A1 A1 A1 | 4 × 10 Mb - ST mm fiber
A2 A2 A2 A2 | 4 × 100 Mb - ST mm fiber
A3 A3 A3 A3 | 4 × 100 Mb - SC mm fiber
A4 A4 A4 A4 | 8 × 10/100 Mb RJ45 copper
A5 A5 A5 A5 | 2 × 10 Mb - ST mm fiber + 4 × 10/100 Mb RJ45 copper
A6 A6 A6 A6 | 2 × 100 Mb - ST mm fiber + 4 × 10/100 Mb RJ45 copper
A7 A7 A7 A7 | 2 × 100 Mb - SC mm fiber + 4 × 10/100 Mb RJ45 copper
A8 A8 A8 A8 | 2 × 100 Mb - SC sm fiber 20 km + 4 × 10/100 Mb RJ45 copper
AA AA AA AA | 4 × 100 Mb - LC mm fiber + 4 × 10/100 Mb - RJ45 copper
AB AB AB AB | 8 × 100 Mb - LC mm fiber
AC AC AC AC | 4 × 100 Mb - LC sm fiber + 4 × 10/100 Mb - RJ45 copper
AD AD AD AD | 8 × 100 Mb - LC sm fiber
AE AE AE AE | 2 × 100 Mb - LC sm fiber + 6 × 10/100 Mb - RJ45 copper
AF AF AF AF | 2 × 10 Mb - ST mm fiber + 2 × 100 Mb - ST mm fiber
AH AH AH AH | 8 x 100 Mb - MTRJ mm fiber
AJ AJ AJ AJ | 4 x 100 Mb - MTRJ mm fiber + 4 x 10/100 Mb - RJ45 copper
AK AK AK AK | 2 x 100 Mb - MTRJ mm fiber + 6 x 10/100 Mb - RJ45 copper
G3 G3 G3 G3 | 1 × 1000 Mb - SC mm fiber 2 km + 2 x 100 Mb - SC mm fiber
G4 G4 G4 G4 | 1 × 1000 Mb - SC mm fiber 2 km + 4 × 10/100 Mb - RJ45 copper
G5 G5 G5 G5 | 2 × 1000 Mb - SC mm fiber 2 km
G6 G6 G6 G6 | 1 × 1000 Mb - RJ45 copper
G7 G7 G7 G7 | 1 × 1000 Mb - SC mm fiber 2 km
G8 G8 G8 G8 | 1 × 1000 Mb - SC sm fiber 10 km
GC GC GC GC | 1 × 1000 Mb - RJ45 copper + 2 × 100 Mb - SC mm fiber
GD GD GD GD | 1 × 1000 Mb - RJ45 copper + 4 × 10/100 Mb - RJ45 copper
GE GE GE GE | 2 × 1000 Mb - RJ45 copper
GF GF GF GF | 1 × 1000 Mb - SC sm fiber 10 km + 2 × 100 Mb - SC mm fiber
GH GH GH GH | 1 × 1000 Mb - SC sm fiber 10 km + 4 × 10/100 Mb - RJ45 copper
GJ GJ GJ GJ | 2 × 1000 Mb - SC sm fiber 10 km
Environment X Standard Environment
H Harsh Chemical Environment Option
Z
ROHS Compliant Version
Y ROHS Compliant Version, with Harsh Chemical Environment Option
